Powersolve PPT15 Series - Manual (Page 2)

Powersolve Electronics Ltd. Units 8A, Arnhem Road, Newbury, RG14 5RU. England
Tel:01635 521858 Fax: 01635 523771 Email: [email protected]
www.powersolve.co.uk
MODEL OUTPUT VOLTAGE MAX LOAD MIN LOAD RIPPLE & NOISE VOLTAGE LINE LOAD
ACCURACY REGULATION REGULATION
PPT15-050 5V 2.0A 0A 50mV ±3% ±1% ±4%
PPT15-060 6V 1.7A 0A 1% ±2% ±1% ±3%
PPT15-090 9V 1.4A 0A 1% ±2% ±1% ±2%
PPT15-120 12V 1.1A 0A 1% ±2% ±1% ±2%
PPT15-150 15V 1.0A 0A 1% ±2% ±1% ±2%
PPT15-180 18V 830mA 0A 1% ±2% ±1% ±2%
PPT15-240 24V 625mA 0A 1% ±2% ±1% ±2%
Note:
1. Voltage setpoint at 60% load.
2. Add a 0.1 µF ceramic capacitor and a 10µF E.L. capacitor to output for Ripple & Noise measuring @20MHz BW.
3. Line regulation measured from 100Vac to 240Vac, full load.
4. Load regulation measured from 60% to full load and from 60% to 20% load (60% +/- 40% load)
Stock items will be fitted with 5.5x2.5x9.5mm barrel connector, centre positive.
Options: Alternative output connectors are available - consult sales office for details.
In-line ferrite core on output cable - consult sales office for details.
AWM *** @@ য়C 300V VW-1SC E146924 ==AWG
80.6(3.17)
47
.9
(1
.8
9)
43
.3
(1
.7
1)
1800(70.86)±30(1.18)
22
.2
(0
.8
7)
±0
.1
3(
0.
00
5)
12
.5
(0
.4
9)
±0
.0
5(
0.
00
2)
17
(0
.6
7)
28
(1
.1
)
18
.4
7(
0.
73
)±
0.
05
(0
.0
02
)
36.35(1.43)
28
.9
(1
.1
4)
18
.1
(0
.7
1)
16
(0
.6
3)
38
.5
(1
.5
2)
4(
0.
16
)
6.
3(
0.
25
)
19
(0
.7
5)
28
(1
.1
)
16
.9
1(
0.
67
)
32
.4
1(
1.
28
)
UNIT: mm (Inches)
Plug Top Power Adaptors
