AC-DC Converters
Note:
MAX POWER: 60 Watts convection cooled, 78 Watts peak for <30 seconds with a maximum 10% duty cycle.
RIPPLE & NOISE: Maximum peak to peak noise expressed as a percentage of output voltage, 20 MHz bandwidth, input at nominal line voltage,
0.1uF and 47uF capacitor on outputs.
LOAD REGULATION: Load test conditions are from minimum, 50% and 100% load conditions on each output.
*Minimum loading of 10% required on all outputs of multi output units, to achieve regulation specified.
MODEL OUTPUT 1 OUTPUT 2 OUTPUT 3 OUTPUT 4 TOTAL REGULATION RIPPLE & NOISE Pk-Pk
PPS60LB-10 5V 12A ±3% ±1%
PPS60LB-11 12V 5A ±3% ±1%
PPS60LB-12 15V 4A ±3% ±1%
PPS60LB-13 24V 2.5A ±3% ±1%
PPS60LB-14 48V 1.25A ±3% ±1%
PPS60LB-15 3.3V 12A ±5% ±1.5%
PPS60LB-20 * +5V 6A +12V 3A ±5% both outputs ±1% both outputs
PPS60LB-21* +5V 6A +24V 1.3A ±5% both outputs ±1% both outputs
PPS60LB-22* +5V 6A -5V 6A ±5% +5V, ±10% -5V ±1% both outputs
PPS60LB-23* +12V 2.5A -12V 2.5A ±5% +12V, ±10% -12V ±1% both outputs
PPS60LB-24* +15V 2A -15V 2A ±5% +15V, ±10% -15V ±1% both outputs
PPS60LB-25* 3.3V 7.5A +12V 3A ±5% both outputs ±1% both outputs
PPS60LB-26* +5V 8A +48V 0.5A ±5% +5V, ±10% +48V ±1% both outputs
PPS60LB-30* +5V 5A +12V 2.5A -5V 1A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS60LB-31* +5V 6A +12V 2.2A -12V 0.4A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS60LB-32* +5V 6A +15V 1.6A -15V 0.4A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS60LB-33* +5V 7.5A +15V 1.2A -5V 0.8A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS60LB-34* +5V 7.5A +15V 1.2A -12V 0.4A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS60LB-35* +5V 5.2A +24V 1.2A -12V 0.4A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS60LB-36* +5V 3A +12V 3.5A -12V 0.4A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS60LB-37* +5V 5.2A +12V 2A +24V 0.4A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS60LB-38* +5V 4A +12V 1.5A +48V 0.6A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS60LB-40* +5V 6A +12V 2A -12V 0.4A -5V 0.4A O/P 1&2 ±5%, O/P 3&4 ±10% ±1% all outputs
PPS60LB-41* +5V 6A +12V 1.6A -5V 0.6A -12V 0.6A O/P 1&2 ±5%, O/P 3&4 ±10% ±1% all outputs
PPS60LB-42* +5V 6A +12V 1A -15V 0.6A +15V 0.6A O/P 1&2 ±5%, O/P 3&4 ±10% ±1% all outputs
PPS60LB-43* +5V 3.3A +12V 1.5A -12V 0.6A -15V 1.2A O/P 1&2 ±5%, O/P 3&4 ±10% ±1% all outputs
PPS60LB-44 +5V 3.3A +12V 0.6A -12V 0.6A +48V 0.6A O/P 1&2 ±5%, O/P 3&4 ±10% ±1% all outputs
PPS60LB-45 +5V 6A +12V 1A -12V 1A +24V 0.5A O/P 1&2 ±5%, O/P 3&4 ±10% ±1% all outputs
PPS60LB-46 +3.3V 6A +5V 2A +12V 2A -12V 1A O/P 1&2 ±5%, O/P 3&4 ±10% ±1% all outputs
PPS60LB-47 +3.3V 6A +5V 4A +12V 1.5A -12V 0.6A O/P 1&2 ±5%, O/P 3&4 ±10% ±1% all outputs
