Powersolve PSE60C Series - Manual (Page 2)

Powersolve Electronics Ltd. Units 8A, Arnhem Road, Newbury, RG14 5RU. England
Tel:01635 521858 Fax: 01635 523771 Email: [email protected]
www.powersolve.co.uk
MODEL NO OUTPUT VOLTAGE OUTPUT CURRENT MAXIMUM OUTPUT
POWER
PSE60C-05 5VDC 4.00A 20W
PSE60C-09 9VDC 4.44A 40W
PSE60C-12 12VDC 4.17A 50W
PSE60C-15 15VDC 3.67A 55W
PSE60C-18 18VDC 3.33A 60W
PSE60C-19 19VDC 3.16A 60W
PSE60C-24 24VDC 2.5A 60W
PSE60C-48 48VDC 1.25A 60W
Output Voltage/Current Rating Chart - PSE60C Series
Standard models have 1.8 metre lead fitted with 2.5x5.5x11 female barrel connector, wired centre positive.
Options: Alternative output connectors available, consult sales office with your requirements.
Any output voltage available within the range of 3V to 50V DC.
Some options subject to minimum order quantities.
5.0
0.1
–5.
23
0.1
–0.
81
1
52.0–1.0
0.
4
R -
4
SWITCHING
POWER
NOTE:
1. Dimensions are shown in mm.
2. Weight: 350 - 400gs approx.
MECHANICAL DIMENSIONS
MM
Desk Top Power Supplies
