Features
• Universal Input: 90 - 264Vac
• Continuous Short Circuit Protection
• Over Voltage Protection
• Conductive EMI Meets CISPR/FCC Class B
• High Efficiency, 75% Typical
• Interchangeable AC plug
• Optional output connectors
INPUT
Voltage 90-264 VAC
Frequency 47-63 Hz
Input current 0.7A max
Inrush Current 50A max @ 264VAC
Isolation Input to output = 4,242VDC
Leakage Current 0.25mA max
OUTPUT
Holdup Time 10mS typ. @ 115VAC
Short Circuit Protection Continuous (Auto Recovery)
Over Voltage Protection Yes
ENVIRONMENTAL
Operating temperature 0°C to 40°C
Storage temperature -20°C to +85°C
GENERAL
Dimensions 107.8x57.6x33.5 mm
Weight 284 grams approx
Typical at 25°C, nominal line and 75% load, unless otherwise specified
Specifications
The PPT30 Series of AC-DC Power Adaptors offer user
interchangeable AC input plugs to enable operation in many
different countries simply by changing the clip on plug.
Adaptors can be ordered with up to 4 interchangeable plugs to
meet the power socket requirements of most countries.
Plug Top Power Adaptors
PPT30 Series
30 Watt Switch Mode
Universal AC Input
