Fully encapsulated Power Supplies

=

2 Package Styles available: – for PCB Mounting with Solder Pins

– for Chassis Mounting with Screw Terminal Block

=

Single-, Dual- and Triple-Output Models

=

Universal Input 85–264 VAC, 47–440 Hz

=

EMI meets EN 55022, Class B

=

Short Circuit and Overload Protection

=

Safety Class ll

AC/DC Power Modules

TPM Series, 5 - 40 Watt

Input voltage range:

85–264 VAC and 47–440 Hz, 100–375 VDC

Line regulation:

±0.5% max.

Load regulation:

±0.5% max.

Ripple & Noise:

<100 mVpk-pk (20 MHz BW)

EMI suppression:

EN 55011 class B, EN 55022 class B and FCC, level B

EMC immunity:

EN 61000-6-2 (industrial environment)

Output current limitation:

105–130% Iout max., constant current

Efficiency:

70–80% (depending on model)

Operating temperature:

–25°C … +60°C above 50°C derating 5%/°C

Safety standards / approvals:

cUL/UL 60950, EN 60950

Degree of protection:

safety class ll

Case:

plastic (UL94V-0 rating)

Type

Length

Width

Height

l

w

h

TPM 05

51 (2.0)

51 (2.0)

20 (0.79)

TPM 10/15

76 (2.99)

51 (2.01)

22.5 (0.89)

TPM 10C/15C

110 (4.33)

51 (2.01)

23 (0.91)

TPM 30

90 (3.54)

65 (2.56)

33 (1.30)

TPM 30C

120 (4.75)

65 (2.56)

33 (1.30)

TPM 40

90.5 (3.58) 65.5 (2.59) 33.5 (1.33)

TPM 40C

120 (4.75)

65 (2.56)

33 (1.30)

Dimensions

Order code

Output power

Output 1

Output 2/3

TPM 05105

5 VDC / 1000 mA

TPM 05112

12 VDC / 420 mA

TPM 05124

5 W

24 VDC / 210 mA

TPM 05212

+12 VDC / 250 mA

–12 VDC / 150 mA

TPM 05215

+15 VDC /150 mA

–15 VDC / 150 mA

**TPM 10105

5 VDC / 2000 mA

**TPM 10112

12 VDC / 840 mA

**TPM 10124

24 VDC / 420 mA

**TPM 10212

10 W

+12 VDC / 400 mA

–12 VDC / 400 mA

**TPM 10215

+ 15 VDC / 300 mA

–15 VDC / 300 mA

**TPM 10512

*5 VDC /1200 mA

±12 VDC / ±120 mA

**TPM 10515

*5 VDC / 1200 mA

±15 VDC / ±100 mA

**TPM 15105

5 VDC / 3000 mA

**TPM 15112

12 VDC / 1300 mA

**TPM 15124

24 VDC / 600 mA

**TPM 15212

15 W

+12 VDC / 600 mA

–12 VDC / 400 mA

**TPM 15215

+15 VDC / 500 mA

–15 VDC / 400 mA

**TPM 15512

*5 VDC / 1600 mA

±12 VDC / ±150 mA

**TPM 15515

*5 VDC / 1600 mA

±15 VDC / ±150 mA

**TPM 30105

5 VDC / 6000 mA

**TPM 30112

12 VDC / 2500 mA

**TPM 30124

24VDC / 1300 mA

**TPM 30212

12 VDC / 1200 mA

–12 VDC / 1200 mA

**TPM 30215

30 W

15 VDC / 1000 mA

–15 VDC / 1000 mA

**TPM 30252

*5 VDC / 3000 mA

*12 VDC / 1200 mA

**TPM 30254

*5 VDC / 3000 mA

*24 VDC / 600 mA

**TPM 30512

*5 VDC / 3000 mA

±12 VDC / ±600 mA

**TPM 30515

*5 VDC / 3000 mA

±15 VDC / ±500 mA

**TPM 40105

5 VDC / 7000 mA

**TPM 40112

40 W

12 VDC / 3300 mA

**TPM 40124

24 VDC / 1800 mA

** suffix C: Chassis Mounting (Example: TML 30105 C) * Output floating
