MODEL OUTPUT VOLTAGE MAX LOAD MIN LOAD RIPPLE & NOISE VOLTAGE LINE LOAD
ACCURACY REGULATION REGULATION
PPT30M-050 5.0V 4.0A 0A 1% ±2% ±1% ±6%
PPT30M-090 9.0V 3.0A 0A 1% ±2% ±1% ±3%
PPT30M-120 12V 2.5A 0A 1% ±2% ±1% ±2%
PPT30M-150 15V 2.0A 0A 1% ±2% ±1% ±2%
PPT30M-180 18V 1.65A 0A 1% ±2% ±1% ±2%
PPT30M-240 24V 1.25A 0A 1% ±2% ±1% ±2%
Note:
1. Voltage setpoint at 60% load.
2. Add a 0.1 µF ceramic capacitor and a 10µF E.L. capacitor to output for Ripple & Noise measurement @20MHz BW.
3. Line regulation measured from 100Vac to 240Vac, full load.
4. Load regulation measured from 60% to full load and from 60% to 20% load (60% +/- 40% load)
Stock items will be fitted with 5.5x2.5x9.5mm barrel connector, centre positive.
Options: Alternative output connectors are available - consult sales office for details.
In-line ferrite core on output cable - consult sales office for details.
Plug Top Power Adaptors
AWM *** @@ য়C 300V VW-1SC E146924 ==AWG
107.8(4.24)
57
.6
(2
.2
7)
33
.5
(1
.3
2)
1.
4(
0.
06
)
1800(70.86)±30(1.18)
22
.2
(0
.8
7)
±0
.1
3(
0.
00
5)
12
.5
(0
.4
9)
±0
.0
5(
0.
00
2)
17
(0
.6
7)
28
(1
.1
)
18
.4
7(
0.
73
)±
0.
05
(0
.0
02
)
36.35(1.43)
28
.9
(1
.1
4)
18
.1
(0
.7
1)
16
(0
.6
3)
38
.5
(1
.5
2)
4(
0.
16
)
6.
3(
0.
25
)
19
(0
.7
5)
28
(1
.1
)
16
.9
1(
0.
67
)
32
.4
1(
1.
28
)
UNIT: mm (Inches)
