Powersolve S280 Series - Manual (Page 2)

Page 4 SPECIFICATIONS Rev. Sept. 2012
Di men sions
Eurorack mount ing
with front panel FP40
Wall mount ing with
front panel FPW
Re dun dant adapter
RA 10 for S28 - 10
An a log Pro gramming CV CC
Pro gramming in puts
in put range
ac cu racy
in put im ped ance 0 - 5 V
± 0.2% - 5 mV / + 12 mV
5 kOhm
0 - 5 V
± 0.5% - 4 mV / + 20 mV
5 kOhm
Mon i toring out put
out put range
ac cu racy
out put im ped ance not avail able 0 - 5 V
± 0.5% − 6 mV / + 0 mV
20 Ohm
Re cov ery time
50 - 100% load step : 100 µs S6-40, S28-10
200 µs S15-18
In su la tion
In put/Out put : 3750 Vrms (1 min.)
8 mm creepage/clear ance
In put/case : 2500 Vrms (1 min.)
Out put/case : 500 V DC
Safety : EN 60950 EN 61010
EMC
Power Sup ply Stan dard : EN 61204-3
Ge neric Emis sion
: EN 61000-6-3 (EN 55022B)
Ge neric Im mu nity : EN 61000-6-2
Op er at ing am bi ent temp. : –20 to +50 °C
Ther mal pro tec tion : Out put shuts down in case
of in suf fi cient cool ing
Se ries op er a tion : Max. 500 V to tal volt age
Re mote sens ing : Max. 2 V per lead
OVP ad just range : 5 - 35 V
Mount ing : Ver ti cal air flow through the
unit should not be ob -
structed
Cooling : Nat u ral con vec tion cool ing,
no blower, no noise.
MTBF : 500 000 hrs
Standby in put power : 4 W
Hold-up time
100 % load, 220 V AC : 20 ms
50 % load, 220 V AC : 40 ms
Di men sions (h x w x d) : 106 x 194.5 x 166 mm
Case : DIN 41494 / IP20
Con nec tors : H15 (DIN 41612)
Weight : 2.8 kg
In ter nal cir cuit of pro gram ming in puts
Out put con nec tor FP40, front panel for Eurocard-rack
FPW front panel for wall mount ing
