UNINTERRUPTIBLE POWER SUPPLIES
WALL MOUNTING, LONG BACK UP PERIOD
Electrical Specification
Input
Nominal AC Input: 230VAC or 115VAC (115VAC not available on 4000VA unit)
200V/220V/230V/240V or 100V/110V/115V/120V Selectable
Input Frequency: 47 to 65 Hz, 50/60 auto sensing
Efficiency:: 97% normal mode, 85% under battery power
Noise Filtering: Full time EMI/RFI filtering
Overcurrent Protection: 230V models 800VA/1200VA fuse protected, all others resettable trip
Voltage Range: 230V models 140V-310V, 115V models 70-155V
AVR Range (2 Bucks, 2 Boosts): Enhanced Buck: +28% of selected V, Buck Mode: +10% of selected V
Boost Mode: -10% of selected V, Enhanced Boost: -25% of selected V
Surge Protection: 230V models 800VA/1200VA: 220 Joules, 1600VA-4000VA: 440 Joules
115V models 800VA/1200VA: 216 Joules, 1600VA-3200VA: 324 Joules
Output
Output Power:
See model rating table
Output Voltage: 200V/220V/230V/240V or 100V/110V/115V/120V Selectable
Output Waveform: Pure Sine Wave
Crest Factor: 3:1
Output Frequency: Auto Select for 50/60Hz, syncronised to incoming AC mains supply
Regulation (nominal): ±10% typical of nominal voltage
Regulation (under battery): ±3% of selected output voltage (adjustable with remote set-up software)
Transfer Time: Blackout: 3mS typical, Brownout: 1mS typical, Battery to Normal: 1mS typical
Over Current Protection: Overload Alarm: 100-120%, Overload shutdown: 120-190% (adjustable)
Battery
Battery Type:
Lead Acid 50Ah to 500Ah (recommended)
Typical back up time: No limit, depends on batteries used (externally)
Charging Method: Smart pulse charging with two charging modes. Quick charging when
battery is not fully charged, trickle charge when battery is 90% fully charged
Maximum Charging Current: See table
Average Charging Voltage: Fast charging: 14V, 28V, 42V or 56V depending on battery voltage
Float charging: 13.5V, 27V, 40.5V or 54V (adjustable with set up software)
Protection: Over current protection & Over charging protection (SCR control)
Thermal protection (CPU control), when temperature inside the unit is higher than 45°C,
charger will stop for 2 minutes, followed by 2 minutes charging. The cycle will be repeated
until temperature drops.
Monitoring: Smart monitoring & warning for failed battery or open-circuit battery.
Auto detection each time when power on or over 6 days
Communications & Management
Standard Interface Port:
UPSilon2000 compatible, optional RS232 and or USB
Optional Interface Port: RJ45 (surge protection), DB9, SNMP (external type)
Control Panel: LED 800VA/1200VA, LCD others
Audible Alarm: Low Battery & Battery Overvoltage, Over load, Short Circuit, Over Temp
Green Mode Function:
(auto shut off in black out) 1% to 14% of full load (adjustable by using remote set up software)
The default setting is off
Cooling: Temperature controlled fan
Environment
Operating Temperature:
0° to 40°C
Storage Temperature: -15° to +55°C
Relative Humidity: 5 to 95% non condensing
Operating Altitude 0 to 3000 metres
Dimensions & Weight See table
