Powersolve PPS25LB Series - Manual (Page 2)

Powersolve Electronics Ltd. Units 8A, Arnhem Road, Newbury, RG14 5RU. England
Tel:01635 521858 Fax: 01635 523771 Email: [email protected]
www.powersolve.co.uk
AC-DC Converters
Note:
MAX POWER:
25 Watts convection cooled, 33 Watts peak for <30 seconds with a maximum 10% duty cycle.
RIPPLE & NOISE: Maximum peak to peak noise expressed as a percentage of output voltage, 20 MHz bandwidth, input at nominal line voltage,
0.1uF and 47uF capacitor on outputs.
LOAD REGULATION: Load test conditions are from minimum, 50% and 100% load conditions on each output.
*Minimum loading of 10% required on all outputs of multi output units, to achieve regulation specified.
MODEL OUTPUT 1 OUTPUT 2 OUTPUT 3 TOTAL REGULATION RIPPLE & NOISE Pk-Pk
PPS25LB-10 5V 5A ±3% ±1%
PPS25LB-11 12V 2.08A ±3% ±1%
PPS25LB-12 15V 1.66A ±3% ±1%
PPS25LB-13 24V 1.04A ±3% ±1%
PPS25LB-14 48V 0.52A ±3% ±1%
PPS25LB-15 3.3V 5A ±5% ±1.5%
PPS25LB-20* +5V 3.75A +12V 0.58A ±5% both outputs ±1% both outputs
PPS25LB-21* +5V 3.75A +24V 0.34A ±5% both outputs ±1% both outputs
PPS25LB-22* +5V 3.75A -5V 1.25A ±5% +5V, ±10% -5V ±1% both outputs
PPS25LB-23* +12V 1.08A -12V 1.08A ±5% +12V, ±10% -12V ±1% both outputs
PPS25LB-24* +15V 0.83A -15V 0.83A ±5% +15V, ±10% -15V ±1% both outputs
PPS25LB-25* 3.3V 5A +5V 2A ±5% both outputs ±1% both outputs
PPS25LB-26* +5V 1A +48V 0.5A ±5% +5V, ±10% +48V ±1% both outputs
PPS25LB-30* +5V 3.33A +12V 0.42A -5V 0.83A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS25LB-31* +5V 3.33A +12V 0.42A -12V 0.33A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS25LB-32* +5V 3.33A +15V 0.33A -15V 0.33A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS25LB-33* +5V 2.5A -5V 0.83A +15V 0.58A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS25LB-34* +5V 2.5A -12V 0.4A +15V 0.5A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS25LB-35* +5V 2.5A -12V 0.42A 24V 0.33A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS25LB-36* +5V 1A +12V 1.5A -12V 0.4A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS25LB-37* +5V 2.5A +12V 0.42A +24V 0.33A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS25LB-38* +5V 1.67A +12V 0.83A +48V 0.17A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
