January 2010

Page 1 - 2

PSC-CP

Output voltage and current setting and read back

• 14 bit resolution for setting the output voltage and current
• 14 bit resolution for read back (monitoring) of the output voltage and current
• Tc typical 15 ppm/K
• Full scale accuracy < 0.1 %
• Factory offset and full scale calibration in combination with power supply

Status monitoring

The following power supply statuses can be read: ACF, DCF, LIM, OT, PSOL and CC

• ACF = AC Fail

• OT = Overtemperature

• DCF = DC Fail

• PSOL = Power Sink Overload

• LIM = Voltage and current limit reached

• CC = Constant Current mode

CANopen features

• SYNC Object

• Expedited and Nonexpedited SDO transfer

• Emergency object

• Node address range 1 - 127

• Node guarding

• Baud rate setting range 10 kbit/s - 1 Mbit/s

• Heartbeat

PROFIBUS features

• Slave in a PROFIBUS-DP network
• DP-V0 standar

d according to IEC 61784 Ed. 1:2002 CPF 3/1

• PROFIBUS protocol according IEC 61158
• Slave address range 1 - 127

ES150 - Se ries

Op tion P279 PROFIBUS

An a log pro gram ming con nec tor removed

ES150 - Se ries

Op tion P280 CANopen

Analog pro gram ming con nec tor removed

ES 030-10

Op tion P281 PROFIBUS

An a log pro gram ming con nec tor removed

ES 030-10

Op tion P282 CANopen

An a log pro gram ming con nec tor removed

SM 800 - Se ries

Op tion P271 FROFIBUS

An a log pro gram ming con nec tor still available

SM 800 - Se ries

Op tion P272 CANopen

An a log pro gram ming con nec tor still available

SM 1500 - Se ries Op tion P273 PROFIBUS

An a log pro gram ming con nec tor still available

SM 1500 - Se ries Op tion P274 CANopen

An a log pro gram ming con nec tor still available

SM 3000 - Se ries Op tion P275 PROFIBUS

An a log pro gram ming con nec tor removed

SM 3000 - Se ries Op tion P276 CANopen

An a log pro gram ming con nec tor removed

SM 6000 - Se ries Op tion P277 PROFIBUS

An a log pro gram ming con nec tor still avail able **

SM 6000 - Se ries Op tion P278 CANopen

An a log pro gram ming con nec tor still avail able **

Mod els

Op tion code

In ter face

Com ments

Controls

The power supply can be set in RSD mode.

• RSD = Remote Shut Down: shuts down the output of the power supply.

**Note : Ex cept on SM 600-10 and SM 300-20
