AC-DC Converters
Note:
CONVECTION COOLING: Current ratings in ( ) are maximum continuous output with convection cooling.
Maximum total power is 130 Watts under these conditions.
PEAK CURRENT: Peak output currents of 125%, lasting <30 seconds with a maximum of 10% duty cycle can be taken, subject to maximum
150 Watts peak load.
RIPPLE & NOISE: Maximum peak to peak noise expressed as a percentage of output voltage, 20 MHz bandwidth, input at nominal line voltage,
0.1uF and 47uF capacitor on outputs.
LOAD REGULATION: Load test conditions are from minimum, 50% and 100% load conditions on each output.
*Minimum loading of 10% required on all outputs, to achieve regulation specified.
MODEL OUTPUT 1 OUTPUT 2 OUTPUT 3 OUTPUT 4 TOTAL REGULATION
PPS180-10 5V 36A (26A) +/-3%
PPS180-11 12V 15A (11A) +/-3%
PPS180-12 15V 12A (8.7A) +/-3%
PPS180-13 24V 7.5A (5.5A) +/-3%
PPS180-14 48V 3.75A (2.7A) +/-3%
PPS180-15 36V 5A (3.6A) +/-3%
PPS180-16 56V 3.2A (2.35A) +/-3%
PPS180-17 18V 10A (7.25A) +/-3%
PPS180-18 3.3V 36A (26A) +/-5%
PPS180-20* +5V 22A (10A) +12V 9A (4.2A) +/-5% both outputs
PPS180-21* +5V 22A (15A) +24V 4.5A (3.3A) +/-5% both outputs
PPS180-22* +5V 22A (15A) -5V 22A (15A) +/-5% both outputs
PPS180-23* +12V 9A (6.3A) -12V 9A (6.3A) +/-5% both outputs
PPS180-24* +15V 7.2A (5A) -15V 7.2A (5A) +/-5% both outputs
PPS180-25* +3.3V 25A (16.5A) +12V 10A (6.3A) +/-5% both outputs
PPS180-26* +12V 10.5A (7.1A) +24V 4A (2.7A) +/-5% both outputs
PPS180-27* 10.3V 8.5A (6.3A) 24V 4.8A (3.6A) +/-5% both outputs
PPS180-28* 5V 25A (20A) 3.3V 18A (14.5A) +/-5% both outputs
PPS180-30* +5V 22A (15A) +12V 9A (6A) -5V 1.5A (0.9A) O/P 1&2 +/-5%, O/P 3 +/-10%
PPS180-31* +5V 22A (15A) +12V 7.5A (6A) -12V 2A (0.9A) O/P 1&2 +/-5%, O/P 3 +/-10%
PPS180-32* +5V 22A (15A) +15V 6A (4A) -15V 1.5A (1A) O/P 1&2 +/-5%, O/P 3 +/-10%
PPS180-33* +5V 25A (21A) +15V 5.5A (3A) -5V 3A (0.9A) O/P 1&2 +/-5%, O/P 3 +/-10%
PPS180-34* +5V 25A (19.2A) +15V 5.5A (3A) -12V 2A (0.9A) O/P 1&2 +/-5%, O/P 3 +/-10%
PPS180-35* +5V 20A (13.8A) -12V 1.3A (0.9A) +24V 4.5A (3A) O/P 1&2 +/-5%, O/P 3 +/-10%
PPS180-36* +5V 20A (13.8A) +12V 8A (6A) -12V 2A (1.5A) O/P 1&2 +/-5%, O/P 3 +/-10%
PPS180-37* +5V 20A (13.8A) +12V 7.5A (5.4A) +24V 1.2A (0.8A) O/P 1&2 +/-5%, O/P 3 +/-10%
PPS180-38* +5V 10A (6.7A) +24V 2.7A (1.8A) +12V 9A (6A) O/P 1&2 +/-5%, O/P 3 +/-10%
PPS180-39* +18V 5.8A (4A) -18V 5.8A (4A) +5V 3A (2A) O/P 1&2 +/-5%, O/P 3 +/-10%
PPS180-40* +5V 22A (15A) +12V 7.5A (5.3A) -12V 1.2A (0.8A) -5V 1.2A (0.8A) O/P 1&2 +/-5%, O/P 3&4 +/-10%
PPS180-41* +5V 22A (15A) +12V 6.3A (4.2A) -12V 2.2A (1.5A) -5V 2.2A (1.5A) O/P 1&2 +/-5%, O/P 3&4 +/-10%
PPS180-42* +5V 22A (15A) +12V 4.5A (2.7A) -15V 2.2A (1.5A) +15V 2.2A (1.5A) O/P 1&2 +/-5%, O/P 3&4 +/-10%
PPS180-43* +5V 13.5A (9A) +12V 5.2A (3.5A) -12V 2.2A (1.5A) -15V 4.5A (3A) O/P 1&2 +/-5%, O/P 3&4 +/-10%
PPS180-44* +5V 13A (9A) +12V 3A (1.5A) -12V 2.2A (1.5A) +48V 2.2A (1.5A) O/P 1&2 +/-5%, O/P 3&4 +/-10%
PPS180-45* +5V 18A (15A) +12V 6.3A (2A) -12V 1.2A (1A) +24V 1.8A (1.5A) O/P 1&2 +/-5%, O/P 3&4 +/-10%
PPS180-46* +5V 6A (4A) -15V 1.85A (1.25A) +15V 1.2A (0.8A) +24V 6A (4A) O/P 1&2 +/-5%, O/P 3&4 +/-10%
PPS180-47* +5V 19A (13A) +15V 1.65A (1.1A) -15V 1.65A (1.1A) +48V 1.65A (1.1A)
PPS180-48Y +5V 20A (12.5A) +3.3V 15A (9A) +12V 2A (2A) -12V 2A (2A)
PPS180-49Y +5V 20A (12.5A) +3.3V 15A (9A) +12V 2A (2A) +24V 1A (2A)
