AC-DC Battery Backed Power Supply
Mechanical and Connection Details
Input Connector:
3 pin 5.08mm terminal block
Output Connector:
6 pin 3.96mm (0.156”) Molex Header
Pin 1 & 2: +5V
Pin 3, 4 & 5: Return
Pin 6: +12V
Battery Connector:
2 x 6.3 x 0.8mm Fast On Blades
Signal Connectors (TB1 & TB2):
2.54mm (0.1”) Molex Headers
