AC-DC Converters
Note:
MAX POWER:
40 Watts convection cooled, 52 Watts peak for <30 seconds with a maximum 10% duty cycle.
RIPPLE & NOISE: Maximum peak to peak noise expressed as a percentage of output voltage, 20 MHz bandwidth, input at nominal line voltage,
0.1uF and 47uF capacitor on outputs.
LOAD REGULATION: Load test conditions are from minimum, 50% and 100% load conditions on each output.
*Minimum loading of 10% required on all outputs of multi output units, to achieve regulation specified.
MODEL OUTPUT 1 OUTPUT 2 OUTPUT 3 TOTAL REGULATION RIPPLE & NOISE Pk-Pk
PPS40LB-10 5V 8A ±3% ±1%
PPS40LB-11 12V 3.33A ±3% ±1%
PPS40LB-12 15V 2.66A ±3% ±1%
PPS40LB-13 24V 1.66A ±3% ±1%
PPS40LB-14 48V 0.83A ±3% ±1%
PPS40LB-15 3.3V 8A ±5% ±1.5%
PPS40LB-20* +5V 4A +12V 2.5A ±5% both outputs ±1% both outputs
PPS40LB-21* +5V 6A +24V 0.5A ±5% both outputs ±1% both outputs
PPS40LB-22* +5V 5A -5V 3A ±5% +5V, ±10% -5V ±1% both outputs
PPS40LB-23* +12V 2A -12V 2A ±5% +12V, ±10% -12V ±1% both outputs
PPS40LB-24* +15V 1.4A -15V 1.4A ±5% +15V, ±10% -15V ±1% both outputs
PPS40LB-25* 3.3V 8.9A +12V 0.9A ±5% both outputs ±1% both outputs
PPS40LB-26* +5V 1A +48V 0.8A ±5% +5V, ±10% +48V ±1% both outputs
PPS40LB-30* +5V 3A +12V 2A -5V 0.5A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS40LB-31* +5V 3A +12V 2A -12V 0.5A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS40LB-32* +5V 3A +15V 2A -15V 0.5A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS40LB-33* +5V 3A +15V 2A -5V 0.5A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS40LB-34* +5V 3A +15V 1.5A -12V 0.5A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS40LB-35* +5V 3A +24V 1A -12V 0.5A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS40LB-36* +5V 1A +12V 2.5A -12V 0.5A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS40LB-37* +5V 3A +12V 1.5A +24V 0.5A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
PPS40LB-38* +5V 2A +12V 0.5A +48V 0.6A O/P 1&2 ±5%, O/P 3 ±10% ±1% all outputs
