©2008, General Electric Company. All rights reserved.

300 00189 Rev D

MC12-205

ISO

9001:2008

QUALITY

MANAGEMENT

SYSTEM

The Americas
GE Analytical Instruments
6060 Spine Road
Boulder, CO 80301-3687 USA
T +1 800 255 6964
T +1 303 444 2009
F +1 303 527 1797
[email protected]
www.geinstruments.com

Europe/Middle East/Africa
GE Analytical Instruments
Unit 3, Mercury Way
Urmston, Manchester
UK M41 7LY
T +44 (0) 161 864 6800
F +44 (0) 161 864 6829
[email protected]

Asia Pacific
GE Analytical Instruments
7/F, Building 2, No. 5 Hua Tuo Rd,
ZhangJiang Hi-Tech Park, Pudong
Shanghai, China 201203
T +(8621) 38777735
F +(8621) 38777469
[email protected]

Consumables

UV Lamp

6 months

Acid Reagent

As needed, typically 3–6 months for continuous on-line analysis, or 6–12 months for laboratory analysis

Oxidizer Reagent

As needed, typically 3-month stability; available in 150- or 300-mL cartridge

Pump Tubing

12 months

Resin Bed

12 months

Capsule Filter

As needed, up to 12 months on finished drinking water

Analyzer Specifications

5310 C Laboratory

5310 C On-Line

5310 C Portable

Outputs

Serial (RS-232) output (2); USB

port (1); parallel printer port (1);

Ethernet

4-20mA output (1); alarm out-

puts (2); binary output (1); Serial
(RS-232) output (2): USB port (1);

parallel printer port (1); Ethernet

4-20mA output (1); Serial

(RS-232) output (2); USB port (1);

parallel printer port (1); Ethernet

Display

Quarter-VGA, color touch-sensitive LCD display

Power

Universal Power Supply: 100–240

± 10% VAC, 100 W

,

50/60 Hz

Universal Power Supply: 100–240

± 10% VAC, 100 W

,

50/60 Hz

Universal Power Supply: 100–240

± 10% VAC, 100 W

,

50/60 Hz

Dimensions

H: 48.3 cm (19.0 in); W: 19.2 cm

(7.6 in); D: 48.0 cm (18.9 in)

H: 62.4 cm (24.6 in); W: 45.2 cm

(17.8 in); D: 26.4 cm (10.4 in)

H: 35.6 cm (14.0 in); W: 22.3 cm

(8.8 in); D: 46.5 cm (18.3 in)

Weight

14.3 kg (31.5 lb)

16.9 kg (37.2 lb)

12.5 kg (27.5 lb)

Safety Certifications

ETL, CE

Enclosure Rating

NA

IP-45

NA

Operating Specifications

2

5310 C Laboratory

5310 C On-Line

5310 C Portable

Range

4 ppb to 50 ppm

Precision

< 1% RSD

Accuracy

± 2% or ± 0.5 ppb, whichever is greater

Sample Type

Autosampler or discrete grab

sample

On-line continuous or discrete

grab sample

On-line continuous, Autosampler,

or discrete grab sample

Display Readout

3 significant digits

Calibration

Typically stable for 12 months

Analysis Time

4 minutes

Sample Temperature

3

1–95° C (34–203° F)

Ambient Temperature

10–40° C (50–104° F)

Sample Pressure

3

N/A

Up to 250 psi

Sample Flow Rate

N/A

50–300 mL/min

Instrument Sample
Flow Rate

0.5 mL/min

Specifications — 5310 C Laboratory, On-Line, and Portable Analyzers

1 5310 C On-Line paired with separate external multi-stream device.

2 Stated analytical performance is achievable under controlled laboratory conditions that minimize operator and standards errors.

3 If the sample temperature and pressure are above 60° C and 100 psi, the stainless steel iOS is required.

The Sievers 900 Series TOC Analyzers are protected by one or more of the following US and foreign patents: US 7247498; US 6271043;
US 5976468; US 5837203; US 5443991; EP 0897530; FR 0897530; GB 0897530; DE 69702516.0-08 . Other patents pending

This information herein may be subject to change without notice and is provided for general guidance only. The dimensions and performance of systems, products and
services may vary. Pictures are for example purposes and not to scale. All legal obligations are exclusively as set out in contractual documents. Nothing contained herein con-
stitutes a representation, warranty or undertaking.
