22

LNK/ACT

FDX/COL

TEMP

PS

FAN A / FAN B

Glows green when a link is established on port.
Blinks green when data activity occurs.

Glows yellow when port is in Full-Duplex mode.
Blinks yellow when port is operating in Half-
Duplex mode and collisions occur.

Glows yellow when temperature of unit
surpasses a user-defined level.

Glows yellow when one power supply module
malfunctions.

Glows yellow when a fan malfunctions.
