8
Dual DC, Part Number 850-10960-2DC
*Does not support redundancy.
ACDC, Part Number 850-10960-ACDC
NOTE
For 850-10960-XX iMediaChassis/20, all models in that model number series can
support Dual AC, Dual DC or ACDC. The power supply modules for that model
number series are interchangeable.
Redundant DC Power Supply, Close-Up
Power
Supply
Module
1 (PS1)
Power
Supply
Module
2 (PS2)
PS
Release
Screw
Reset
Alarm
Switch
Power
Connector
Power
Supply
Status
LED
Redundant ACDC Power Supply, Close-Up
Power
Supply
Module
1 (PS1)
Power
Supply
Module
2 (PS2)
PS
Release
Screw PS
Release
Screw
Reset
Alarm
Switch
DC Power
Connector
PS1
Status
LED
AC Power
Connector
PS2 Status
LED
