Temperature Gauge
The iMediaChassis/3 includes a temperature monitoring gauge with a heat sensor on
the backplane of the chassis. Users define a threshold for chassis temperature via
SNMP. If the chassis’ temperature rises above the specified level, the SNMP agent
sends a trap (configured in iView²) to the administrator. There is also an LED
indicator on the SNMP Management Module for chassis temperature.
Installing the iMediaChassis/3
Install the chassis first before installing any modules into an iMediaChassis.
When installing the chassis, be sure to observe the following precautions to prevent
electrical or mechanical damage:
1. Stay within the chassis’ power rating to prevent overload of supply circuits or
damage to any overcurrent protection and supply wiring.
2. Maintain reliable ground, especially when connecting to a power strip instead of
directly to a branch circuit.
3. Protect the chassis from exposure to sunlight and electrical or magnetic fields.
4. Ensure that the equipment rack remains stable, even with the addition of the
chassis and its associated cabling.
Use the iMcV-MediaChassis/3 as a table-top chassis, mount in a Rackmount shelf or
mount it to a wall surface.
To install the 3-slot Rackmount in the chassis:
1. Install the iMcV-MediaChassis/3 by placing it on a flat surface.
2. Make sure to leave adequate space on the sides of the unit to accommodate
cooling.
3. If mounting on a Rackmount shelf, align holes of the chassis to the shelf and
secure with screws.
The Rackmount shelf is sold separately. To purchase the Rackmount shelf (part
number (895-39949); visit the IMC Networks’ Product Accessories page:
https://www.imcnetworks.com/Products/acc.cfm
Rackmounting requires a Rackmount shelf for mounting up to two units side by side.
4. Attach the cables between the chassis and the device that will be
interconnected, and then plug the unit into a reliable, filtered power source.
