(Revised 8/3/2009) Page 4 of 138
7018TX, 7018FX2, and 7018FXE2 Industrial Ethernet Switch Installation Guide
The N-TRON 7018 Series Industrial Ethernet Switch offers outstanding performance and ease of use. It is
ideally suited for connecting Ethernet enabled industrial and or security equipment and is a fully managed
switch.
PRODUCT FEATURES
• Full IEEE 802.3 Compliance
• Fourteen 10/100 BaseTX RJ-45 Ports
• Sixteen 10/100 BaseTX RJ-45 Ports (7018TX model
only)
• Two Optional Gigabit ports:
o 1000BaseSX/LX Ports, LC style, and/or
o 1000BaseT Ports, RJ45 style
• Two Optional 100BaseFX(E) Ports (7018FX2 and
7018FXE2 models only)
• Extended Environmental Specifications
• Auto Sensing 10/100BaseTX, Duplex, and MDIX
• Offers Rapid Spanning Tree Protocol
• Trunk with other N-Tron trunking capable switches
over two ports
• Store & Forward Technology
• Plug and Play IGMP Support
• Rugged Din-Rail Enclosure
• Redundant
Power Inputs (10-30 VDC)
o –HV High Voltage Option (40-160VDC)
• SNMP v1, v2 and v3.
• Web Browser Management with detailed ring map and
fault location charting.
• Web Browsing and N-View Switch Monitoring
PRODUCT CONFIGURATIONS
•
7018TX-VV
– Sixteen 10/100 Base-TX RJ45 Copper Ports, and two
optional SFP transceivers
• 7018FX2-XX-VV
– Fourteen 10/100 Base-TX RJ45 Copper Ports,
two multimode 100BaseFX Ports, and two optional SFP
transceivers
• 7018FXE2-XX-YY-VV
– Fourteen 10/100 Base-TX RJ45 Copper Ports, two
singlemode 100BaseFX Ports and two optional SFP
transceivers
Where: XX = ST or SC
YY = 10, 40 or 80 for Singlemode, Blank for Multimode
E = Singlemode, Blank Otherwise
VV = HV for High voltage, Blank for Standard voltage
MANAGEMENT FEATURES
• IGMP Snooping
• VLAN
• QoS
• Port Trunking
• Port Mirroring
• 802.1D-2004 Rapid Spanning Tree
• N-RING™ (N-Tron proprietary Ring Management)
• N-LINK™ (N-Tron proprietary Coupling Management)
• DHCP Server, Option 82 relay
