100 Mb Fiber Transceiver Characteristics
Fiber Length
2km*
15km**
40km**
80km**
TX Power Min/Max
-19dBm/-14dBm
-15dBm/-7dBm
-5dBm/0dBm
-5dBm/0dBm
RX Sensitivity Max
-32dBm
-34dBm
-34dBm
-34dBm
Wavelength Min/Max
1310nm
1310nm
1310nm
1550nm
* Multimode Fiber Optic Cable
** Singlemode Fiber Optic Cable
Gigabit Fiber Transceiver (SFP) Characteristics
Fiber Length
550m* with
50/125 µm
10km**
40km**
70km**
TX Power Min/Max
-9.5dBm/-4dBm
-9.5dBm/-3.5dBm
-2dBm/3dBm
0dBm/5dBm
RX Sensitivity Max
-17dBm
-20dBm
-22dBm
-24dBm
Wavelength
850nm
1310nm
1310nm
1550nm
Assumed Fiber Loss
-0.5 dB/km
-0.35 dB/km
-0.25 dB/km
Laser Type
VCSEL
FP
DFB
DFB
*SX Fiber Optic Cable
** LX Fiber Optic Cable
Regulatory Approvals:
Safety: UL listed per ANSI/ISA-12.12.01-2007 (US and Canada)
This equipment is suitable for use in Class I, Div 2, Groups A, B, C, and D or non-hazardous
locations only.
EMI: FCC Title 47, Part 15, Subpart B - Class A
ICES-003 – Class A
EMS: EN61000-4-2 (ESD)
EN61000-4-3 (RS)
EN61000-4-4 (EFT)
EN61000-4-5 (Surge)
EN61000-4-6 (Conducted Disturbances)
