MG260 Product Specification
This document is the sole and exclusive property of FLYFOT. Not to be distributed or divulged without prior written
agreement.
5.2 Environmental qualification
Test Designation Standards Definition / Severities
Resistance to Heat IEC 60068-2-2 Temperature:
+85°C Duration:
Resistance to
cold test IEC 60068-2-30 Db Storage temperature: -40 2
°C Storage time: 72 h
Cooking Test - Temperature: +70
2°C Duration: 100
Damp heat test IEC 60068-2-3 Storage temperature: +40
2°C Storage humidity: HR 95
3% Storage time: 21 days
Damp heat cycle
test IEC 60068-2-30 Db Upper temperature: +55
2°C Storage humidity: HR
95
3% Number of cycles:
Temperature
change IEC 60068-2-14 Nb Low temperature: -40° 2°C
High temperature: +85
2°C Total duration: 11
Thermal Shock IEC 60068-2-14 Low temperature: -40° 2°C
High temperature: +85
2°C Total duration: 200
Resistance
to sinusoidal
vibration IEC 60068-2-6 Fc [10 Hz to 16 Hz]: 5 mm (peak)
[16 Hz to 62 Hz]: 5 g (peak)
[62 Hz to 200Hz]: 3 g (peak)
[200 Hz to 1000 Hz] 1g (peak)
Test duration: 20 cycles
Sweep directions: X / Y / Z
Resistance
to random
vibration IEC 60068-2-64 Frequency range: 10 Hz - 2000 Hz
Spectrum level:
• 0.1 g 2 /Hz at 10 Hz
• 0.01 g 2 /Hz at 250 Hz
• 0.0005 g 2 /Hz at 1000 Hz
• 0.0005 g 2 /Hz at 2000 Hz
Duration: 16 h
Vibration axis: X / Y / Z
Resistance
to mechanical
shock IEC 68-2-27 Peak acceleration: 30 g / 100 g /
200 g
Direction:
±X, ±Y, ±Z
ESD Test IEC 1000-4-2 1 kV contact discharge on 80-pin
connector
2 kV contact discharge on RF
connector
For more details refer to Automotive Environmental Control Plan ([1]).
