2.9.9 GPS activation

Signal

Pin

I/O

I/O type

Level

Comment

GPS_EN

21

I/O

CMOS

2.8 V / 2X

VIL

≤ 0.3 VCC*

VIH

≥ 0.7 VCC*

VOL

≤ 0.1V

VOH

≥ 2.7 V

Output: 100

k

Ω

impedance

*VCC = 2.8 V






























、
