MG260 Product Specification
This document is the sole and exclusive property of FLYFOT. Not to be distributed or divulged without prior written
agreement.
3 RF interface
3.1 RF connectors
The RF connections between the MG260 module and the customer application
are made by two MMS type coaxial connectors, manufactured by Murata.
Both RF connectors are available on the bottom side of the module, named:
• GSM/DCS RF connector
• GPS RF connector
Note:
FLYFOT strongly recommends not to use IMS plug equivalent connectors,
because it does not mate correctly with the Mutata receptacle.
