AT49BV/LV040
4
Notes: 1. The 16K byte boot sector has the address range 00000H to 03FFFH.
2. Either one of the Product ID Exit commands can be used.
Command Definition (in Hex)
Command
Sequence Bus
Cycles
1st Bus
Cycle
2nd Bus
Cycle
3rd Bus
Cycle
4th Bus
Cycle
5th Bus
Cycle
6th Bus
Cycle
Addr Data Addr Data Addr Data Addr Data Addr Data Addr Data
Read 1 Addr D
OUT
Chip Erase 6 5555 AA 2AAA 55 5555 80 5555 AA 2AAA 55 5555 10
Byte Program 4 5555 AA 2AAA 55 5555 A0 Addr D
IN
Boot Block Lockout (1) 6 5555 AA 2AAA 55 5555 80 5555 AA 2AAA 55 5555 40
Product ID Entry 3 5555 AA 2AAA 55 5555 90
Product ID Exit (2) 3 5555 AA 2AAA 55 5555 F0
Product ID Exit (2) 1 XXXX F0
Absolute Maximum Ratings*
Temperature under Bias ................................ -55 °C to +125°C *NOTICE: Stresses beyond those listed under “Absolute Maxi-
mum Ratings” may cause permanent damage to the
device. This is a stress rating only and functional
operation of the device at these or any other condi-
tions beyond those indicated in the operational sec-
tions of this specification is not implied. Exposure to
absolute maximum rating conditions for extended
periods may affect device reliability.
Storage Temperature ..................................... -65 °C to +150°C
All Input Voltages
(including NC Pins)
with Respect to Ground ...................................-0.6V to +6.25V
All Output Voltages
with Respect to Ground .............................-0.6V to V
CC
+ 0.6V
Voltage on OE
with Respect to Ground ..................................-0.6V to + 13.5V
