Byte-Wide Read Mode AC Waveforms
(1)
Note: 1. BYTE/V
PP
= V
IL
Byte-Wide Read Mode AC Waveforms
(1)
Note: 1. BYTE/V
PP
= V
IH
BYTE Transition AC Waveforms
Notes: 1. Timing measurement references are 0.8V and 2.0V. Input AC drive levels are 0.45V and 2.4V, unless otherwise specified.
2. OE may be delayed up to t
CE
- t
OE
after the falling edge of CE without impact on t
CE.
3. OE may be delayed up to t
ACC
- t
OE
after the address is valid without impact on t
ACC
.
4. This parameter is only sampled and is not 100% tested.
5. Output float is defined as the point when data is no longer driven.
A18
A18
A0 - A18
A-1
O - O
0 7
BYTE/V
PP
t
ACC
t
ST
t
STD
t
OH
t
OH
O - O
8 15
HI-Z
VALID
VALID
DATA OUT DATA OUT
DATA OUT
