6. Retrofit Installation
PNEG-1895 V2 Electronic Distributor Control 45
Proximity Sensor Adjustment
Set the clearance of the two (2) proximity sensors (DEC0107) (A) to 0.050" ± 0.01" from the face of each
sensor to the flag (B) on the shaft (DEC0009).
(See Figure 6F.) This adjustment may need to be made
after motor is wired by using manual key switch to locate flag above each proximity sensor.
Figure 6F Proximity Sensor Adjustment
Ref # Part # Description
A DEC0107 Proximity Sensor
B Flag
