4. Operation Procedures
36 PNEG-1895 V2 Electronic Distributor Control
Manual Override
Located on the front of the controller is a manual/jog dial (A). This manual override is key locked and
should only be used in case of a major equipment failure. It allows for manually moving the spout in the
direction you turn the dial when the key is inserted.
It is recommended that two (2) people perform this procedure. One person to operate the manual/jog
dial (A) and another to look through the distributor and verify alignment of the spout.
(See Figure 4AA.)
NOTE: Panel will not close with key inserted in the manual/jog dial (A). Always keep key in a safe location
for access by authorized personnel only.
Figure 4AA
Ref # Description
A Manual/Jog Dial
A
