3. Connect one end of an Ethernet cable to the Ethernet connector on the cellular modem.
Please refer to
4. Run the antenna wire for the cellular modem through a knockout in the bottom of the control panel
and connect the BNC connector to the modem. The antenna is magnetized and should be placed
with the least obstructions to the nearest tower.
Figure 8C
5. Return to the “Install Procedure”
Ethernet connector
Antenna connector
