FireSwitch108 - 9 -
Step 2. Program Protocol for channels 1-8:
a. Select from: Steady, Code 3, Follower Mode, Amseco/Potter, Gentex ® , System Sensor ® or CooperWheelock ® .
Protocol Selection:
LCD
Legend
Function Triggered From Description
1a Steady Input 1
A steady output signal will be generated. This mode
will accept steady or pulsing input.
2a Steady Input 2
3a Steady Redundant - Input 1 and Input 2.
1b Code 3 Input 1
Enables Temporal Code 3 signal generation output.
This mode will accept a steady or a pulsing input.
2b Code 3 Input 2
3b Code 3 Redundant - Input 1 and Input 2.
1c Follower Mode Input 1
Output follows signal it receives from the
corresponding input (i.e. FACP Sync module -
maximum synchronization of notification
appliance circuit).
2c Follower Mode Input 2
3c Follower Mode First Input to go in alarm mode.
1d Amseco/Potter Input 1 (both horns and strobes). This mode is designed to work with the Amseco/Potter
series of horns, strobes, and horn/strobes to provide
a means of synchronizing the Temporal-coded horns,
synchronizing the one-second flash timing of
the strobe, and silencing the horns of the horn/strobe
combination over a two-wire circuit while leaving
strobes active.
2d Amseco/Potter Input 2 (both horns and strobes).
3d Amseco/Potter
Input 1 - strobes only,
Input 2 - horns and strobes.
1e Reserved Input 1 (both horns and strobes).
Reserved
2e Reserved Input 2 (both horns and strobes).
3e Reserved
Input 1 - strobes only,
Input 2 - horns and strobes.
1f Gentex ® Input 1 (both horns and strobes). This mode is designed to work with the Gentex
® series
of horns, strobes, and horn/strobes to provide a means
of synchronizing the Temporal-coded horns,
synchronizing the flash timing of the strobe, and
silencing the horns of the horn/strobe combination
over a two-wire circuit while leaving strobes active.
2f Gentex ® Input 2 (both horns and strobes).
3f
Gentex ®
Gentex is a registered trademark
of Gentex Corporation.
Input 1 - strobes only,
Input 2 - horns and strobes.
1g System Sensor ® Input 1 (both horns and strobes). This mode is designed to work with the System
Sensor ® series of horns, strobes, and horn/strobes to
provide a means of synchronizing the Temporal-coded
horns, synchronizing the flash timing of the strobe, and
silencing the horns of the horn/strobe combination
over a two-wire circuit while leaving strobes active.
2g System Sensor ® Input 2 (both horns and strobes).
3g
System Sensor ®
System Sensor is a registered
trademark of Honeywell.
Input 1 - strobes only,
Input 2 - horns and strobes.
1h CooperWheelock ® Input 1 (both horns and strobes). This mode is designed to work with the
CooperWheelock series of horns, strobes, and
horn/strobes to provide a means of synchronizing the
Temporal-coded horns, synchronizing the one-second
flash timing of the strobe, and silencing the horns of
the horn/strobe combination over a two-wire
circuit while leaving strobes active.
2h CooperWheelock ® Input 2 (both horns and strobes).
3h
CooperWheelock ®
CooperWheelock is a
registered trademark of
CooperWheelock.
Input 1 - strobes only,
Input 2 - horns and strobes.
Depress the joystick one (1) time from Function screen or two (2) times from Stand-by screen.
Use [UP/DOWN] to select Protocol, Use [Left/Right] to select outputs.
Use [Right] to copy setting to next output.
Class A outputs are paired.
If output is set for Ax or Bx - Protocol settings are not available.
