Step 3. Read/Clear Trouble Memory
a. Depress the joystick three (3) times from Stand-by screen, or two (2) times from Function Screen,
or one (1) time from Protocol screen.
Trouble Memory LCD Indication:
LCD Legend Trouble Condition
A
AC trouble.
B Battery trouble.
C Common trouble.
N Normal operating condition.
O Loop open or open circuit.
S Loop Shorted.
G Loop Ground fault.
? Loop wiring is incorrect.
Use [Down] to reset all stored troubles.
Step 4. AC and Battery Trouble reporting and Sounder Alert Options
a. Depress the joystick four (4) times from Stand-by screen, or three (3) times from Function Screen,
or two (2) times from Protocol screen, or one (1) time from Trouble Memory screen.
Use [Up/Down] to select/de-select reporting option.
Use [Left/Right] to select AC/BAT/ALERT or to enable/disable AC and BAT trouble and ALERT sounder.
Depress the joystick to exit.
Note: AC and BAT trouble and ALERT sounder are factory enabled.
FireSwitch User Interface and Programming via Ethernet Port:
Note: Service person must be present on site to confirm changes by holding “down” position of joystick.
Step 1. Set Local Area Connection of your laptop to DHCP mode.
For Windows XP:
a. Open Network Connections by clicking Start button, then clicking Settings, then clicking Network Connections.
b. Right click the Local Area Connection. Click Properties. Administrator permission required
If you are prompted for an administrator password or confirmation, type the password or provide confirmation.
c. Double click
Internet Protocol (TCP/IP) menu item.
d. Choose the Obtain an IP address automatically option.
e. Click OK. Close all windows.
For Windows Vista:
a. Open Network Connections by clicking the Start button Picture of the Start button, clicking Control Panel,
clicking Network and Internet, clicking Network and Sharing Center, and then clicking Manage Network
connections.
b. Right click the
Local Area Connection icon, and then click Properties. Administrator permission required
If you are prompted for an administrator password or confirmation, type the password or provide confirmation.
c. Click the
Networking tab. Under this connection uses the following items, click either Internet Protocol
Version 4 (TCP/IPv4) or Internet Protocol Version 6 (TCP/IPv6), and then click Properties.
d. To specify IPv4 IP address settings, click Obtain an IP address automatically, and then click OK.
e. To specify IPv6 IP address settings, click Obtain an IPv6 address automatically, and then click OK.
For Windows 7:
a. Open Network Connections by clicking the Start button Picture of the Start button, clicking Control Panel,
clicking Network and Internet, clicking Network and Sharing Center, and then clicking Change Adapter
Settings.
b. Right click the
Local Area Connection icon, and then click Properties. Administrator permission required
If you are prompted for an administrator password or confirmation, type the password or provide confirmation.
c. Click the
Networking tab. Under this connection uses the following items, click either Internet Protocol
Version 4 (TCP/IPv4) or Internet Protocol Version 6 (TCP/IPv6), and then click Properties.
d. To specify IPv4 IP address settings, click Obtain an IP address automatically, and then click OK.
e. To specify IPv6 IP address settings, click Obtain an IPv6 address automatically, and then click OK.
