Altronix FireSwitch108 Installation Instructions - Manual (Page 7)

FireSwitch108 - 7 -
Common Trouble Sync
Power Limited
Ethernet
Connection
Regulated
Supervised
NAC Outputs
Power Limited
Regulated
NAC Outputs
Power Limited
Aux. Output
Regulated
24VDC @ 1 amp
Power Limited
(0.45 for Canadian
applications)
AC Input
Non-Power Limited
120VAC, 60Hz
4.8 amp
AC and Battery
Supervision
Power Limited
Wiring Diagram:
Fig. 4
ALL POWER LIMITED
WIRING IS TO BE ROUTED
UNDER THE CHASSIS
(BETWEEN CHASSIS AND BACKBOX)
