FireSwitch108

- 19 -

Appendix B - UL Listed Compatible Devices (cont’d)

B.1 Four (4) Wire Smoke Detectors

Table B-1 below lists four (4) wire smoke detectors compatible with FireSwitch outputs 1-8 programmed as AUX.
(Special Application).

System Sensor
Smoke Detector/Base

Detector Type

Max Stand-by Current (mA) Alarm Current (mA)

2112/24ATR

Photoelectric

0.50

60/70

2112/24AITR

Photoelectric

0.50

60/70

2112/24/D

Photoelectric

0.05

50

2112/24R

Photoelectric

0.50

60/70

2112/24TR

Photoelectric

0.50

60/70

2112/24T/D

Photoelectric w/135

o

Thermal

0.05

50

2112/24TSRB

Photoelectric w/135

o

Thermal Supervisory Relay

15

45

2312/24TB

Photoelectric

0.12

50

2412 (12 volt)

Photoelectric

0.12

77

2412AT (12 volt)

Photoelectric

0.12

58

2412TH (12 volt)

Photoelectric

0.12

77

2424

Photoelectric

0.10

41

2424TH

Photoelectric

0.10

41

2451

Photoelectric

0.10

39

2451TH (with/B402B Base)

Photoelectric

0.10

39

2W-MOD

Loop Test/Maintenance Mod.

30

50

4W-B (12/24 volt)

Photoelectric I

3

.05

23

4WT-B (12/24 volt)

Photoelectric I

3

w/Therm

.05

23

4WTA-B (12/24 volt)

I

3

Photo w/Therm/Sounder

.05

35

4WTR-B (12/24 volt)

I

3

Photo w/Therm/Relay

.05

35

4WTR-B (12/24 volt)

I

3

Photo w/Therm/

Sounder/Relay

.05

50

4WITAR-B (12/24 volt)

I

3

Photo w/Isolated Therm/

Sounder/Relay

.05

50

2W-MOD2

I

3

Loop Test/Maintenance

Mod.

.05

*

RRS-MOD

I

3

Reversing Relay/Sync

Module

.05

*

6424

Projected Beam

10

28.4

Beam 1224(S)

Projected Beam

17

38.5

* Contact manufacturer for current draws

B.2 Relays

Table B-3 below lists relays compatible with FireSwitch AUX output.

Manufacturer

Model

Current (mA)

Manufacturer

Model

Current (mA)

System Sensor

PR-1

PR-2

PR-3

EOLR-1

R-10T

R-14T

15

30

30

30

23

23

System Sensor

R-20T

R-24T

R-10E

R-14E

R-20E

R-24E

40

40

23

23

40

40
