Displays and error messages.
The LEDs cannot be seen with the F*D0-FB-Ex*.*** FieldBarrier unless
the cover of the FieldBarrier has been removed.
LED
Function
PWR, green is lit
A suitably high power supply is present on the non-intrin-
sically safe fieldbus segment.
1 to 4, red flashing
There is a short circuit present on the corresponding out-
put.
