Commissioning the FieldBarrier
7.1
Mounting FieldBarriers
7.1.1
Mounting the FieldBarrier F*D0-FB-Ex4.***
You will find information on mounting in chapter 4.4. For information on permissible
cable diameters, conductor cross sections and tightening torques of screws as well
as cap nuts and cable glands, please refer to chapter 4.5.
The handling of the cable gland depends on the type in question.
Always observe the chapter 4 before placing the system in service.
