Switching delay 0.5 s, 3 s or 6 s - Selection via DIL switch
Contact 1 spdt for each output
Contact material AgNi, hard gold-plated
Turn-on voltage ≥ 10 mV DC, ≤ 253 V AC/DC
Switching current ≥ 10 µA DC, ≤ 3 A AC, 1 A DC
Breaking capacity ≤ 750 VA, ≤ 54 W DC
Ambient conditions
Ambient temperature
-
With single mounting -20 … +60 °C (-4 … +140 °F)
-
With mounting in series (without lateral
distance) -20 … +50 °C (-4 … +122 °F)
-
When mounting in protective housing -20 … +40 °C (-4 … +104 °F)
Storage and transport temperature -40 … +70 °C (-40 … +158 °F)
Electromechanical data
Screw terminals for wire cross-section up to 1.5 mm² (AWG 16)
Electrical protective measures
Protection rating IP 20
Overvoltage category II
Protection class II
Electrical separating measures Reliable separation (VDE 0106, part 1) between
power supply, sensor input and level relay
Approvals
Instruments with approvals can have different technical data depending on the version.
That's why the associated approval documents have to be noted with these instruments. They are
part of the delivery or can be downloaded under www.vega.com via "VEGA T
ools" and "serial
number search" as well as via "Downloads" and "Approvals".
