Settings in the "extended menu"
7.12 Special function: Manual correction
Manual offset correction
(only with hydrostatic pressure transmitters)
This correction can be carried out to
compensate changes of the sensor values
due to ageing. In oder to do this, the sensor
must be in an unpressurized condition
(empty vessel).
Param.
TAG-
Nr. 1
TAG -
Nr. 1
%
xx,x
Adjust-
ment Signal
condi-
tioning Out-
puts Simu-
lation Special
func-
tions
Reset
Level Manu-
al
corr.
Offset
correc-
tion
Offset
correc-
tion
OK?
Cor-
rection
Now!
OK ?
Cor-
rection
Now !
OK ?
Real
value
corr.
Real
value
corr.
OK?
Correc-
tion
%
0,0
Manual real value correction
In the menu item "Correction % 0.0" you can
enter a percentage value which corresponds
to the actual level.
1) This menu item only appears if with the measure-
ment loop configuration a correction mode was
adjusted. Then, the percentage value at which the
automatic correction occurs must be set here.
