Veris Industries H938 SERIES Datasheet - Manual (Page 2)

current monit
oring
800.354.8556 +1 503.598.4564 www.veris.com
MODEL AMPERAGE
RANGE
STATUS
OUTPUT(max.)
MIN. TRIP
POINT
RELAY COIL
VOLTAGE
HOUSING STATUS
LED
RELAY
POWER LED
UL
H735 1 - 135A 0.1A@30VAC/DC 1A or less SPST, N.O. 24VAC/DC Solid-core n n n
H738 1 - 135A
1.0A@30VAC/DC
1A or less SPST, N.O. 24VAC/DC Solid-core n n n
H748 1 - 135A 1A or less SPDT 24VAC/DC Solid-core n n n
H758 1 - 135A 1A or less SPST, N.O. 12VDC nom. Solid-core n n n
H938 2.5 - 135A 2.5A or less SPST, N.O. 24VAC/DC Split-core n n n
H948 2.5 - 135A 2.5A or less SPDT 24VAC/DC Split-core n n n
H958 2.5 - 135A 2.5A or less SPST, N.O. 12VDC nom. Split-core n n n
H735/738/748/758 H938/948/958
DIMENSIONAL DRAWINGS
Relay Controlled Directly by Status Contacts
APPLICATION/WIRING DIAGRAMS
Start/Stop Monitoring of Fan /Pump Motors
ORDERING INFORMATION
* Terminal block may extend up to 1/8” over the height dimensions shown.
0.2” x 0.15”
slot (2x)
1.1" *
(27 mm)
2.8"
(68 mm)
0 0.7"
(19 mm)
0.9"
(23 mm)
3.0" **
(75 mm)
Removable/Adjustable Mounting Bracket
3.8"
(95 mm)
4.2"
(106 mm)
Removable Mounting Bracket
Self-gripping Iris
1.0”
(25 mm)
0.8”
(21 mm)
1.1”
(26 mm)
**3.1”
(79 mm)
2.8”
(70 mm)
Ø 0.3”
(8 mm)
1.4”*
(36 mm)
2.5”
(64 mm)
3.0”
(76 mm)
Bracket can
be mounted
on three sides
for added
installation
flexibility.
Fan or Pump
CONTROLLER
DI (Status)
DO (Relay
Coil)
Motor
CONTACTOR
CONTROL
POWER
RELAY LOAD
Relay Coil
Power Source
ACCESSORIES
DIN Rail Clip Set (AH01)
DIN Rail (AV01) and DIN Stop Clip (AV02)
AH01
AV01
AV02
E150462
HQ0001760.B 01131
