Test Products International 440 User Manual
Page 3
4
2
TABLE OF CONTENTS
page
A.
INTRODUCTION
1.
Congratulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2.
Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
3.
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . .4
B.
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . .5
C.
TECHNICAL DATA
1.
Features and Benefits . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
D.
MEASUREMENT TECHNIQUES
1.
Controls and Functions . . . . . . . . . . . . . . . . . .13
2.
Step by Step Procedures:
a)
Measuring DC Volts . . . . . . . . . . . . .15
b)
Measuring AC Volts . . . . . . . . . . . . .16
c)
Measuring DC Amps . . . . . . . . . . . .17
d)
Measuring AC Amps . . . . . . . . . . . .18
e)
Measuring Resistance . . . . . . . . . . .19
f)
Measuring Diodes . . . . . . . . . . . . . .20
g)
Continuity Buzzer . . . . . . . . . . . . . .21
h)
Measuring Capacitance . . . . . . . . . .22
i)
Measuring Frequency . . . . . . . . . . .23
j)
Component Test . . . . . . . . . . . . . . .24
k)
Logic Test . . . . . . . . . . . . . . . . . . . .26
E.
SPECIAL DMM FEATURES & FUNCTIONS . . . .27
F.
D MODE FEATURES & FUNCTIONS . . . . . . . . .29
G.
WAVEFORM MEMORY & SETUP MEMORY . . .32
H.
NORMAL MODE 440 APPLICATIONS . . . . . . . .35
I.
TREND MODE 440 APPLICATIONS . . . . . . . . . .38
J.
GLITCH CAPTURE 440 APPLICATIONS . . . . . .39
K.
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . .40
L.
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . .41
M. RS-232C INTERFACE . . . . . . . . . . . . . . . . . . . .42
N.
TROUBLE SHOOTING GUIDE . . . . . . . . . . . . . .44
