1. Controls and Functions: (cont.)
Selects the Capacitance function.
COMP Selects the Component Test function.
OFF Turns the instrument off.
Input Jacks
A Red test lead connection for current measurements
on the A function (AC and DC amps).
µmA Red test lead connection for current measurement
on the µA and mA functions (AC and DC micro and
milliamps).
COM Black test lead connection for all functions.
V
Ω
Red test lead connection for Volts, Ohms,
Capacitance, Logic and Component Test functions.
RS-232C Output
DB9on See section M on RS-232C interface.
top of 440
