SPECIFICATIONS
Inputs:
Voltage Input
208 to 480VAC, 50/60 Hz RMS 1 ² 3
Current Input
Up to 2400A continuous per phase ² 3
Accuracy:
System Accuracy
±1% of reading from 10% to 100% of the rated current of the CTs, accomplished by matching the CTs with electronics and calibrating them as a system
Outputs:
Type
Modbus RTU 4 5
Baud Rate
9600, 8N1 format
Connection
RS-485, 2-wire + shield
Environmental:
Operating Temperature Range
0° to 60°C (32° F to 140°F), 50°C (122°F) for 2400A
Humidity Range
0 - 95% noncondensing
Agency Approvals UL508
Approved for California CSI Solar applications (check the CSI website for model numbers).
¹ Do not install on the line or load side of a VFD unit, or on any other equipment generating harmonics. For line side applications, use the E5x Series meters.
² Contact factory to interface for voltages above 480VAC or current above 2400 Amps.
3 Do not apply 600 V Class current transformers to circuits having a phase-to-phase voltage greater than 600 V, unless adequate additional insulation is applied between the primary conductor and the current transformers.
Veris assumes no responsibility for damage of equipment or personal injury caused by products operated on circuits above their published ratings.
4 Detailed protocol specifications are available at: http://www.veris.com/modbus
5 Other protocols available. Please consult factory.
Enercept® Networked Power
Transducers (Modbus® RTU)
Year
Warranty
5
FEATURES
●
Revenue Grade measurements
●
Precision electronics and current transformers in a single package...reduces the
number of installed components...creating significant labor savings
●
Monitor energy parameters (kW, kWh, kVAR, PF, Amps, Volts) at up to 63
locations on a single RS-485 network...greatly reduces wiring time and cost
●
Fast split-core installation eliminates the need to remove conductors...saves
time and labor
●
Smart electronics eliminate CT orientation concerns...fast trouble-free
installation
●
CSI approved...eases submission process for California Solar Initiative
DESCRIPTION
The Enercept H8035 and H8036 Series are innovative three-phase networked
(Modbus RTU) power transducers that combine measurement electronics and high
accuracy industrial grade CTs in a single package. The need for external electrical
enclosures is eliminated, greatly reducing installation time and cost.
There are two application-specific platforms to choose from. The Basic Enercept
energy transducers (H8035) are ideal for applications where only kW and kWh
are required. The Enercept Enhanced power transducers (H8036) output 26
variables including kW, kWh, volts, amps, and power factor, making them ideal for
monitoring and diagnostics.
Color-coordination between voltage leads and CTs makes phase matching easy.
Additionally, the Enercept automatically detects and compensates for phase
reversal, eliminating the concern of CT load orientation. Up to 63 Enercepts can be
daisy-chained on a single RS-485 network.
APPLICATIONS
●
Energy managment and performance contracting
●
Monitoring for commercial tenants
●
Activity-based costing in commercial and industrial facilities
●
Real-time power monitoring
●
Load shedding
Integral Monitoring Solution
Eliminates the Need for
Separate Enclosures
U.S. Patent No. 6,373,238
H8035/H8036
H8035 & H8036 SERIES
BACnet
connec
tivity
via new
E8950
Gateway
HQ0001711.C 01131
