setp
oint de
vices
800.354.8556 +1 503.598.4564 www.veris.com
DIMENSIONAL DRAWING
4.9”
(125mm)
3.4”
(87mm)
1.1”
(28mm)
1.25”
(32mm)
1.5”
(37mm)
MANUF. PART # ORDERING # DESCRIPTION COMM.
VT7200F5000 U008-0009
Zone Thermostat with 2 Analog
+ 1 Digital;
PIR ready (PIR cover not
included)
Stand alone
VT7200F5000B U008-0010 BACnet (MS/TP)
VT7200F5000E U008-0011 Echelon
VT7200F5000W U008-0012 Wireless (Zigbee)
VT7200F5500 U008-0013
Zone Thermostat with 2 Analog
+ 1 Digital;
PIR factory-equipped
Stand alone
VT7200F5500B U008-0014 BACnet (MS/TP)
VT7200F5500E U008-0015 Echelon
VT7200F5500W U008-0016 Wireless (Zigbee)
24 VAC ON/OFF relay (4 C.P.H.)
or 24 VAC PWM ( 10 seconds )
8 4 4 5 5
4 7
424
V
5Co
m
.
6BO
5
7BO
5
15
Ui3
14
Bi2
13
Sco
m
12
RS
11
Bi1
9
AO
1
10 8
AO
2
0-10
VDC
9
0-10
VDC
Cooling
valve
Heating
valve
Viconics
R800
series
SSR
Triacs
24 VAC
Transformer
24 VAC ON/OFF relay (4 C.P.H.)
or 24 VAC PWM ( 10 seconds )
9 4 5
4 7
4 24
V
5 Co
m
.
6 BO
5
7 BO
5
15
Ui3
14
Bi2
13
Sco
m
12
RS
11
Bi1
9
AO
1
10 8
AO
2
0-10
VDC
Viconics
R800
series
SSR
Triacs
24 VAC
Transformer
Heating/
Cooling
Valve
15 13
Changeover
Sensor
APPLICATION/WIRING EXAMPLES
Typical 4-Pipe Application
Typical 2-Pipe Application
* Use for heating and cooling valves and electric duct heaters.
* Use for heating and cooling valves, electric duct heaters, and changeover sensors.
ORDERING INFORMATION
HQ0001863.B 01131
