Communicating Thermostats:
Analog Outputs, Zone Control
SPECIFICATIONS
Thermostat Power Requirements 19-30VAC; 50 or 60 Hz; 2VA Class 2
Operating Conditions 0° to 50°C (32° to 122°F); 0 to 95% RH non-condensing
Storage Conditions -30° to 50°C (-22° to 122°F); 0 to 95% RH non-condensing
Temperature Sensor Local 10 K NTC thermistor
Resolution ± 0.1°C (± 0.2°F)
Control Accuracy Temp: ±0.5°C (±0.9°F ) @ 21°C (70°F) typical, calibrated
Occupied and Unoccupied Setpoint Range Cooling 12° to 38°C (54° to 100°F)
Occupied and Unoccupied Setpoint Range Heating 4.5° to 32°C (40° to 90°F)
Room and Outdoor Air Temperature Display -40° to 50°C (-40° to 122°F)
Proportional Band for Room Temperature Range Control Cooling & Heating: 1.8°C (3.2°F )
Binary Inputs Dry contact across terminal BI1, BI2 & UI3 to Scom
Outputs Rating Triac output: 30VAC, 1A max., 3A in-rush; Analog: 0 to 10VDC into 2kΩ resistance min.
Economizer Analog Output Rating 0 to 10VDC into 2kΩ resistance min.
Economizer Analog Output Accuracy ±3% typical
Wire Gauge 18 gauge maximum, 22 gauge recommended
Dimensions 4.94” x 3.38” x 1.13”
Approximate Shipping Weight 0.75 lb (0.34 kg)
UL: 873 (US) and CSA C22.2 No. 24 (Canada), File E27734 with CCN , XAPX (US) and XAPX7 (Canada)
FCC: Compliant to CFR 47, Part 15, Subpart B, Class A (US)
Industry Canada: ICES-003 (Canada)
CE: EMC Directive 89/336/EEC (European Union)
C-Tick: AS/NZS CISPR 22 Compliant (Australia / New Zealand); Supplier Code Number N10696
DESCRIPTION
The VT7200F5x00 series features a backlit LCD display with dedicated function
menu keys for simple operation. Accurate temperature control is achieved using
the PI proportional control algorithm. Models have two analog 0-10VDC outputs.
Remote room sensing is also available. All models contain an auxiliary contact that
can be used to control lighting or auxiliary reheat. All devices are also available with
Echelon, BACnet MS-TP, or wireless network adapters.
APPLICATIONS
● Heating/Cooling valves
● Electric duct heaters
● Changeover sensors
BACnet, Echelon, And Wireless
Models Available
Year
Warranty
2
VT7200F5000 VT7200F5500
FEATURES
● Advanced occupancy functions through the network or smart local occupancy
sensing
● 3 configurable inputs...adds functionality
● Pre-configured sequences of operation...one model meets more applications...
reduces project delivery cost
● Unique local configuration utility...minimizes parameter tampering
● Lockable keypad...tamper proof, no need for thermostat guards
● Available for analog control...meet advanced applications requirements
● Auxiliary output...can be used for lighting or reheating
● Available with various open industry standard communication adapters...adds
network integration functionality for additional savings
