Veris Industries H5xx SERIES Datasheet - Manual (Page 2)

current monit
oring
800.354.8556 +1 503.598.4564 www.veris.com
ORDERING INFORMATION
DIMENSIONAL DRAWING
MOUNTING OPTIONS
Mounts directly on 2-gang junction box
Mounts directly on 4-gang junction box Mounts directly on wall or panel
Enclosure Mount
APPLICATION/WIRING DIAGRAM
POWER
SOURCE
IN SERIES
RELAY
HOA
SWITCH
CURRENT SENSOR
= CIRCUIT PATH
EXHAUST FAN
DIGITAL OUT
24V
STATUS IN
CONTROLLER
MODEL AMPERAGE
RANGE
STATUS OUTPUT TRIP POINT RELAY RELAY
COIL
HOA
SWITCH
STATUS
LEDS
RELAY
POWER LED
UL
H535 0.25 - 15A Relay Only SPST, Field-Selectable N.O/N.C.
24VAC/DC
n n n
H535NS 0.25 - 15A Relay Only SPDT n n
H540 0.25 - 15A N. O., 1.0A@30VAC/DC 0.25A or less, Fixed SPST, Field-Selectable N.O/N.C n n n
H540NS 0.25 - 15A N. O., 1.0A@30VAC/DC 0.25A or less, Fixed SPDT n n
H548 0.5 - 15A N. O., 1.0A@30VAC/DC 0.5A or less, Adjustable SPST, Field-Selectable N.O/N.C n n n n
H548NS 0.5 - 15A N. O., 1.0A@30VAC/DC 0.5A or less, Adjustable SPDT n n n
H500
ACCESSORIES
Ground bonding kit (AH10)
Note: See installation guide for
wiring requirements
Line Voltage
Wires
Low Voltage
Wires Only
1/2" Conduit
Fitting
Low Voltage
Wires Only
Line Voltage Wires
1/2" Conduit
Fitting
ENCLOSURE
Nipple to
Existing
Enclosures
Status Output & Relay Coil
(Low Voltage Wires Only)
Low Voltage
Wires Only
RS
OC
SO
SP
SC
Line Voltage
Wires
2.2"
(55 mm)
1.16"
(30 mm)
4.25"
(108 mm)
1.6"
(39 mm)
CL
Wire
Opening
Wire
Opening
Wire
Opening
1.2"
(30 mm)
4.25"
(108 mm)
CL
CL
(Low Voltage Only)
E150462
HQ0001771.B 01131
