pressure
800.354.8556 +1 503.598.4564 www.veris.com
Example:
PD 50 A X
DIMENSIONAL DRAWINGS
PD SERIES
Pressure Range
= 17 - 4SS
Output
= Display only
Material
50 = -14.7 to 50 psig
100 = -14.7 to 100 psig
250 = -14.7 to 250 psig
500 = -14.7 to 500 psig
1000 = -14.7 to 1000 psig
PD A X
Display Only Version Analog Output Version
APPLICATION/WIRING DIAGRAM
Analog Output Version
Display Only Models Analog Output Models
Pressure Range Output Material
PD A
= 17 - 4SS M = 4-20mA
V = 0-5VDC/0-10VDC
50 = 0 to 50 psig
100 = 0 to 100 psig
250 = 0 to 250 psig
500 = 0 to 500 psig
1000 = 0 to 1000 psig
ORDERING INFORMATION
connector
locking screw
red/black/white
red/black
supply voltage
7.5 to 32VDC
control panel
4-20 mA input 15’ lead
(4.5m)
On
Off
Min
Max
Units Zero
VERIS INDUSTRIES
http://www.veris.com
1-800-354-8556 ®
1-503-598-4564
Digital Pressure Gauge
1/4” MNPT
1.8”
(45mm)
4”
(100mm)
3.6”
(91mm)
5/8”
0.7”
(17mm)
3.1”
(79mm)
1.8”
(44mm)
1.3”
(33mm)
2.2”
(55mm)
5/8”
connector
locking screw
15’ lead
(4.5m)
red
black
white
supply voltage
15 to 32 VDC
control panel
4-20 mA input
Voltage Output Version
HQ0001826.B 01131
