Installation Guide
Temperature
TK
TM
Dimensions
Length as ordered
0.3"
(6.3 mm)
1. Mount probe using the Veris AA64 or similar mounting clip.
2. Wire as shown below.
Orange
Orange
Thermistor
RTD
Installation
