Veris Industries H120 SERIES Datasheet - Manual (Page 2)

current monit
oring
800.354.8556 +1 503.598.4564 www.veris.com
Voltage Coil Current
AC DC
24V.................................. 75mA
32mA
TYPICAL COIL PERFORMANCE
Resistive........................ 20A(r)*@277VAC/28VDC
(250,000 Cycles)
Motor............................. 120VAC, 1HP
208VAC, 1HP
250VAC, 2HP
277VAC, 2HP
Ballast........................... 277VAC, 20A
Tungsten....................... 120VAC, 10A
RELAY CONTACT RATINGS (N.O.)
*See operating temperature specification
ORDERING INFORMATION
MODEL AMPERAGE RANGE COIL RELAY STATUS OUTPUT TRIP POINT HOUSING RELAY POWER LED UL
H120
0.1A - 20A 24VAC/DC SPST, N.O.
N.O. 100mA@30VAC/DC
0.1A or less Nipple Mount
n n
H120NC N.C. 100mA@30VAC/DC n n
DIMENSIONAL DRAWING
WIRE COLOR CODES
Common
24VAC/DC
VOLTAGE
wht/blue
COMM
wht/yellow
Common
N.O.
CONTACT OUTPUT CONTROL SYSTEM INPUT
White ORANGE
White ORANGE
blue blue
yello
w
yello
w
*Isolation…600VAC
*
Nipple mount to 4x electrical box
APPLICATION/WIRING DIAGRAMS
Nipple mount directly to a panel
Relay Contacts
Current Switch
POWER
SOURCE
Fractional
HP Motor
To Load
To Controls
CON
TACTS
RELAY
DO (coil)
DI (current
switch)
GREY
COMMON
N.O.
GREY
H120 STATUS OUTPUT
BROWN
COMMON
N.C.
BROWN
H120NC STATUS OUTPUT
ORDERING INFORMATION
1.6"
(41 mm)
1.7"
(43 mm)
1/2" NPT Nipple
1.8"
(46 mm)
2.9"
(74 mm)
2.8"
(71 mm)
