Veris Industries LD2100 Datasheet User Manual
Distance read panel, Helps eliminate high humidity false alarms, Le ak dete ction

LE
AK DETE
CTION
VERIS INDUSTRIES
800.354.8556
+1 503.598.4564
www.veris.com
Helps Eliminate High
Humidity False Alarms
Distance Read Panel
DESCRIPTION
Together with our SC, SC-C, or SC-H sensing cable, the LD1500 and LD2100 panels
detect and report the presence and exact location of the cable-specific fluid. When
the fluid comes in contact with the patented cable, the monitoring panel quickly
pinpoints the location of the leak, triggering an alarm and displaying the location.
FEATURES
●
Adjustable leak and contamination alarm thresholds to prevent false alarms
due to high humidity...high detection accuracy
●
RS-232 port allows configuration with PC
SPECIFICATIONS
Input Power
24VAC@600mA max., 50/60 Hz; 24VDC@600mA max.
Inputs:
Water Leak Detection Cable
Requires 15 ft. (4.5 m) leader cable kit (LC-KIT or LC-KIT-M)
Maximum Length
1500 ft. (457 m); LD2100: 2000 ft. (609 m)
Detection Accuracy
± 2 ft (0.6 m) + 0.5% of the cable length
Detection Repeatability
± 2 ft (0.6 m) + 0.25% of the cable length
Detection Response Time
5-995 sec ± 2 sec
Outputs:
Relay (LD2100 only)
1A@24VDC, 0.5A resistive@120VAC
Communications Ports:
RS-232
9600 baud, No parity, 8 data bits, 1 stop bit
RS-485
1200, 2400, 9600, or 19200 baud (selectable); No parity, 8 data bits, 1 stop bit
Protocols:
Terminal Emulation (RS-232)
VT100 compatible
Modbus (RS-485)
Slave; RTU Mode; Supports function codes 03, 04, 06, and 16; Johnson N2 (LD2100 only)
Expanded Protocols:
TCP/IP, HTML, TFTP IPv4.0
SNMP
V1: V2C MIB-2 compliant; NMS Manageable with Get, Set, Traps
SMTP (email, LD2100 only)
Supports client authentication (plain and login); compatible with ESMTP servers
Modbus TCP/IP
Modbus slave; TCP/IP transmission protocol
BACnet/IP
ASHRAE Std 135-2004 Annex J
Alarm Notification:
Audible Alarm
LD2100: 70 dBA@2 ft. (0.6 m); re-sound configurable (disabled, 0 to 24 hours, integer values only)
Visual Alarm
LD1500: Red, 4-digit; 7 segment LED display; bi-color status LED; LD2100: bi-color status LED
Email (LD1500/LD2100)
4 email recipients; email sent on Alarm and Return to Normal
SNMP Traps (LD1500/LD2100)
4 community strings
Logging Capabilities:
Event Log
LD1500: Last 10 events; LD2100: Last 500 events
Trend Log
LD2100: Cable current level every day, for the last 288 days
Login Security :
Display Access
1 Administrator (password for configuration, no password required to view panel status)
Front Panel Interface:
Display
LD2100: green alphanumeric dot matrix
Push Buttons
LD2100: Test/Rest; LD5200: Up, down, right, left, enter
LED Indicator
LD1500: 1 tri-color Power/Status (green = power on; red = alarm; yellow = cable fault; LD2100: 1 bi-color Power/Status (green=power on, red=alarm)
Operating Environment:
Temperature
0° to 50°C (32° to 122°F)
Humidity
5% to 95% RH non-condensing
Altitude
15000 ft. (4572 m) max.
Mounting
Vertical wall mount (DIN rail mounting option available on LD2100 only)
Agency Approvals
CE; ETL listed: conforms to UL 61010-1, EN 61010-1; CSA C22.2; RoHS compliant,
LD2100
LD1500
LD1500 & LD2100
HQ0001796.B 01131
