SPECIFICATIONS (TW/TEA)
Input Power:
TW Model:
4-20mA mode: loop powered 12 to 30VDC only, 30mA max.; 0-5/0-10V mode: 12-30VDC/24VAC, 15mA max.
TEA Model:
4-20mA mode; loop powered 24VDC only; 0-10V, 3-wire, observe polarity; 12-30DC; 0-5V, 3-wire, observe polarity; 24VAC, 12-30DC
Analog Output (TEA 4-20 mA model)
2-wire, not polarity sensitive (clipped and capped)
Temp Output (TW Model)
2-wire, loop powered 4-20mA or 3-wire, 0-5V/0-10VDC
Transmitter Type
Solid-state, integrated circuit
Accuracy (Transmitter models only)
±0.5°C (±1°F) typical
Ranges:
TW Model:
10° to 35°C (50° to 95°F)/0° to 50°C (32° to 122°F) jumper-selectable
TEA Model:
10° to 35°C (50° to 95°F)
RTD/Thermistors in wall packages are not compensated for internal heating of product.
Wall Mount Temperature Sensors
Wall Mount
Temperature Sensors
SPECIFICATIONS (TE)
Wiring
22 AWG; 2-wire: RTD Thermistor, 4-20mA; 3-wire: Voltage output models
Housing
Black or white ABS plastic
Linitemp:
Input Power
5 to 30VDC
Output
1µA/°C or 10mV/°C
Operating Temperature
-25° to 105°C (-13° to 221°F)
Accuracy:
Calibration Error
1.5°C (2.7°F) typical; 2.5°C (4.5°F) max. at 25°C (77°F)*
Error over Temperature
1.8°C (3.24°F) typical; 3.0°C (5.4°F) max. over 0° to 70°C (32° to 158°F) range;
2.0°C (3.6°F) typical, 3.5°C (6.3°F) max. over -25° to 105°C (-13° to 221°F) range
*Room temperature error documented on each unit.
2-Wire version (1µA/°C)
µA reading - 273.15=Temperature in °C
3-Wire version (10mV/°C)
mV reading/10 - 273.15 = Temperature in
°C
DESCRIPTION
These wall mounted temperature sensors feature a discreet appearance combined with high accuracy and reliability. Aesthetically pleasing in any interior environment.
Flexible mounting options include flush and single-gang for ease of installation.
To compute Linitemp Temperature:
TABLE OF STANDARD RTD AND THERMISTOR VALUES
Z202030-0R
page 1
©2012 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [email protected]
02121
Class
Pt RTD
THERMISTOR
Type
100 Ohm
1000 Ohm
2.2k
3k
10k Type 2 10k Type 3
10k Dale
10k 3A221 10k “G” US
20k
20k “D”
100k
10k Type 2
10k Type 3
Accuracy
±0.3°C
±0.3°C
±0.2°C ±0.2°C
±1.0°C
±0.2°C
±0.2°C
±1.1°C
±0.2°C
Consult
Consult
Consult
±0.1°C 20/70°C
±0.1°C
0.0385
curve
0.0385
curve
0/70°C
0/70°C
-50/150°C
0/70°C
-20/70°C
0/70°C
0/70°C
Factory
Factory
Factory
±0.2°C 0/20°C
0/70°C
Temp. Response*
PTC
PTC
NTC
NTC
NTC
NTC
NTC
NTC
NTC
NTC
NTC
NTC
NTC
NTC
*PTC: Positive Temperature Coeffi cient
High Accuracy
*NTC: Negative Temperature Coeffi cient
STANDARD RTD AND THERMISTOR VALUES (Ohms Ω)
°C
°F
100 Ohm
1000 Ohm
2.2k
3k
10k Type 2 10k Type 3
10k Dale
10k 3A221 10k “G” US 20k NTC
20k “D”
100k
10k Type 2
10k Type 3
-50
-58
80.306
803.06
154,464 205,800
692,700
454,910
672,300
-
441,200 1,267,600
-
-
692,700
454,910
-40
-40
84.271
842.71
77,081 102,690
344,700
245,089
337,200
333,562
239,700
643,800
803,200
3,366,000
344,700
245,089
-30
-22
88.222
882.22
40,330
53,730
180,100
137,307
177,200
176,081
135,300
342,000
412,800
1,770,000
180,100
137,307
-20
-4
92.160
921.60
22,032
29,346
98,320
79,729
97,130
96,807
78,910
189,080
220,600
971,200
98,320
79,729
-10
14
96.086
960.86
12,519
16,674
55,790
47,843
55,340
55,252
47,540
108,380
122,400
553,400
55,790
47,843
0
32
100.000
1000.00
7,373
9,822
32,770
29,588
32,660
32,639
29,490
64,160
70,200
326,600
32,770
29,588
10
32
103.903
1039.03
4,487
5,976
19,930
18,813
19,900
19,901
18,780
39,440
41,600
199,000
19,930
18,813
20
68
107.794
1077.94
2,814
3,750
12,500
12,272
12,490
12,493
12,260
24,920
25,340
124,900
12,500
12,272
25
77
109.735
1097.35
2,252
3,000
10,000
10,000
10,000
10,000
10,000
20,000
20,000
100,000
10,000
10,000
30
86
111.673
1116.73
1,814
2,417
8,055
8,195
8,056
8,055
8,194
16,144
15,884
80,580
8,055
8,195
40
104
115.541
1155.41
1,199
1,598
5,323
5,593
5,326
5,324
5,592
10,696
10,210
53,260
5,323
5,593
50
122
119.397
1193.97
811.5
1,081
3,599
3,894
3,602
3,600
3,893
7,234
6,718
36,020
3,599
3,894
60
140
123.242
1232.42
561.0
747
2,486
2,763
2,489
2,486
2,760
4,992
4,518
24,880
2,486
2,763
70
158
127.075
1270.75
395.5
527
1,753
1,994
1,753
1,751
1,990
3,512
3,100
17,510
1,753
1,994
80
176
130.897
1308.97
284.0
378
1,258
1,462
1,258
1,255
1,458
2,516
2,168
12,560
1,258
1,462
90
194
134.707
1347.07
207.4
-
919
1,088
917
915
1,084
1,833
1,542
9,164
919
1,088
100
212
138.506
1385.06
153.8
-
682
821
679
678
816.8
1,356
1,134
6,792
682
821
110
230
142.293
1422.93
115.8
-
513
628
511
509
623.6
1,016
816
5,108
513
628
120
248
146.068
1460.68
88.3
-
392
486
389
388
481.8
770
606
3,894
392
486
130
266
149.832
1498.32
68.3
-
303
380
301
299
376.4
591
456
3,006
303
380
Sensor Codes
B
C
E
F
D
H
J
S
R
M
U
T
W
Y
TW
TE
TW & TE SERIES
