SPLINED MIDSHIP TUBE SHAFTS
Companion Flange or End Yoke Design
9
Important: See Safety Information in General Information Section (J300P-GI)
•
Part is discontinued
Part is available until supply is exhausted
Not sold separately
L
Length
of
Spline
K
End of Spline
Spline to
Point of Weld
Thread Size
S
t
y
l
e
Y
End of Spline
to Bearing
Shoulder
B
Shoulder
Diameter
G
Length of
Shoulder
Midship
Tube Shaft
Part Number
Tube
Dia.
Wall
Thickness
Fits Tube
1.250-29 Involute Spline
1.378 Bearing Diameter (C)
3.000 .083
2.440
3.190
2 1.530
1.000-20
1.690
.500
2-53-1411•
1.574 Bearing Diameter (C)
3.000 .083
2.340
3.460
2 1.530
1.000-20
1.810
.880
3-53-2541
3.500 .083
2.149
3.268
2 1.527
1.000-20
1.811
.688
3-53-08000
3.500 .083
2.149
3.268
2 1.527
1.000-20
1.811
.688
5008000•
5008000 was replaced by 3-53-08000
1.375-10 Spline
1.378 Bearing Diameter (C)
2.500 .065
2.688
3.750
2 1.781
1.000-20
1.688
.812
2-53-1211•
2.500 .083
2.688
3.750
2 1.781
1.000-20
1.688
.812
2-53-1191
3.000 .083
2.291
3.969
1 2.000
.500-20
1.688
1.062 3-53-191•
3.000 .083
2.656
4.000
2 1.688
1.000-20
1.719
1.125 3-54-611
3.000 .083
2.688
3.750
2 1.781
1.000-20
1.688
.812
2-53-1151
1.500-10 Spline
1.574 Bearing Diameter (C)
3.000 .083
2.650
3.875
2 1.938
1.000-20
1.812
1.040 3-53-2371X
3.000 .083
2.750
3.875
2 1.940
1.000-20
1.810
.875
3-53-1781
3.000 .083
2.938
4.000
2 1.844
1.000-20
1.938
.812
3-53-1811
3.000 .083
3.590
4.650
2 1.940
1.000-20
1.940
.810
3-53-2321•
3.000 .095
2.750
3.875
2 1.938
1.000-20
1.812
.875
3-53-1891•
3.500 .065
2.750
3.875
2 1.938
1.000-20
1.812
.875
3-53-2061
3.500 .083
2.750
3.875
2 1.940
1.000-20
1.812
.880
3-53-2301
3.500 .083
2.750
3.880
2 1.940
1.000-20
1.810
.890
3-53-1791
3.500 .083
2.969
4.031
2 2.000
1.000-20
1.938
.812
3-53-1821
3.500 .083
3.000
4.406
2 2.031
1.000-20
2.062
1.156 3-53-421•
3.500 .095
2.969
4.031
2 2.000
1.000-20
1.938
.812
4-53-361
4.000 .083
2.750
3.875
2 1.938
1.000-20
1.812
1.125 3-53-1801
4.000 .083
2.969
4.031
2 2.000
1.000-20
1.938
.812
3-53-1831
1.771 Bearing Diameter (C)
3.500 .095
2.969
4.062
2 2.000
1.000-20
2.190
.810
4-53-401
4.000 .083
2.969
4.062
2 2.000
1.000-20
2.188
.810
4-53-271
2.000 Bearing Diameter (C)
3.500 .095
5.375
5.875
2 1.938
1.000-20
2.500
.230
4-53-351•
used with pillow block
1.543-36 Involute Spline
1.574 Bearing Diameter (C)
3.500 .083
2.740
3.538
2 1.875
1.000-20
1.803
.559
55-53-101
1.750-10 Spline
1.771 Bearing Diameter (C)
3.500 .095
3.250
4.344
2 2.281
1.250-18
2.188
.812
5-53-111•
3.500 .134
3.188
4.281
2 2.000
1.250-18
2.188
.812
5-53-141
4.000 .134
3.250
4.344
2 2.281
1.250-18
2.188
.812
5-53-191
