J300P-7 Slip Tube Shafts
Fits Tube K L R
Diameter
Wall
Thickness
Length
of Spline
End of Spline
to Weld
End of
Spline to Radius
Spicer Part
Number
5 Important: See Safety Information in General Information Section (J300P-GI)
• Part is discontinued „ Part is available until supply is exhausted Ž Not sold separately
1.375-16 Spline (Continued)
2.500
.065 5.344 2.250 4.625 2-40-1041
2.500 .065 6.344 2.250 5.625 2-40-1811
2.500 .065 6.844 2.250 6.125 2-40-1291
2.500 .065 8.000 3.625 7.312 2-40-2671•
2.500 .083 5.344 2.250 4.625 2-40-1131
2.500 .083 6.344 2.250 5.625 2-40-1711
2.500 .083 7.100 3.188 6.375 2-40-2801•
2.500 .083 7.375 3.000 6.656 2-40-2871•
2.500 .083 7.531 2.250 6.812 2-40-1851
2.500 .083 7.531 2.250 6.812 2-40-2631 ƒ
Special center in spline end
2.500 .083 7.531 3.625 6.813 2-40-2461
2.500 .083 8.000 3.000 7.310 2-40-2941•
2.500 .083 10.000 3.000 9.375 2-40-2611
2.750 .083 7.390 3.000 6.540 2-40-2891•
3.000 .065 5.625 2.250 4.812 2-40-1211
3.000 .065 6.438 2.250 5.625 2-40-1221
3.000 .065 7.625 2.250 6.812 2-40-2051
3.000 .083 6.050 2.250 5.625 2-40-2811
3.000 .083 6.438 2.250 5.625 2-40-1521
3.000 .083 7.625 2.250 6.812 2-40-2231
3.000 .083 7.625 3.620 6.812 2-40-2691
3.000 .083 8.641 6.781 7.828 2-40-1871 ƒ
3.500 .065 6.625 2.250 5.625 2-40-1671
3.500 .065 7.875 3.625 6.875 2-40-2761
3.500 .083 6.625 2.250 5.625 2-40-1531
3.500 .083 7.906 2.250 6.906 2-40-2041
3.500 .083 7.906 3.625 6.906 2-40-2531
3.500 .083 8.969 6.906 7.969 2-40-2091•
1.375-31 Based On 32 Involute Spline
2.000
.120 6.312 3.000 5.750 2-40-2421•
2.000 .120 7.438 3.531 6.875 2-40-2361
Spline not Glidecoated
2.500 .083 6.344 2.250 5.625 2-40-2501•
Spline not Glidecoated
1.437-21 Based On 22 Involute Spline
3.500
.083 8.281 3.500 7.344 3-40-2241
1.500-15 Based On 16 Spline
2.500
.156 7.812 2.500 7.094 3-42-451
1.500-16 Spline
2.500
.083 5.625 2.500 4.969 3-40-1471
3.000 .083 5.938 2.500 5.125 3-40-1101
3.000 .083 6.281 3.000 5.469 3-40-1511
3.000 .083 7.250 2.500 6.438 3-40-1611
3.000 .083 7.406 3.000 6.594 3-40-1421
3.000 .083 8.250 3.000 7.406 3-40-1911
3.000 .095 6.437 2.500 5.610 3-40-1961•
3.500 .065 6.562 3.000 5.625 3-40-1521•
3.500 .065 7.344 2.500 6.406 3-40-481•
3.500 .083 5.375 2.000 4.438 3-40-2071
3.500 .083 6.562 3.000 5.625 3-40-1531
3.500 .083 6.844 2.500 5.828 3-40-1431
3.500 .083 7.344 2.500 6.406 3-40-1621
3.500 .083 7.531 3.000 6.594 3-40-1491
3.500 .083 10.260 4.000 9.320 3-40-2181
