J300P-7 SPLINED MIDSHIP TUBE SHAFTS
Slip Yoke Design For Use with Outboard Slip Yokes
L K S
t
y
l
e
Y B G Midship
Tube Shaft
Part
Number
Tube
Diameter
Wall
Thickness
Fits Tube
End of Spline
to Bearing
Shoulder
End of Spline
to Point of
Weld
Length
of
Spline
Shoulder
Diameter Length of
Shoulder
13 Important: See Safety Information in General Information Section (J300P-GI)
• Part is discontinued „ Part is available until supply is exhausted Ž Not sold separately
1.4370-21 Based On 22 Involute Spline
1.575 Bearing Diameter (C)
3.000 .065 7.460 8.080 2 3.500 1.800 .375 3-53-02255
May use boot 212094X, order separate
3.000 .065 7.460 8.080 2 3.500 1.800 .375 5002255•
5002255 was replaced by 3-53-02255; May use boot 212094X, order separate
3.000 .083 9.500 10.618 2 3.500 1.810 .889 3-53-12525
May use boot 212010X, order separate
3.000 .083 9.500 10.618 2 3.500 1.810 .889 5012525•
5012525 was replaced by 3-53-12525; May use boot 212010X, order separate
3.000 .083 9.500 10.620 2 3.500 1.810 .880 3-53-2451
May use boot 211503X, order separate
3.500 .083 7.923 8.803 — 3.500 1.809 .880 3-53-07287
3.500 .083 7.923 8.803 — 3.500 1.809 .880 5007287•
5007287 was replaced by 3-53-07287
3.500 .065 7.385 8.000 2 3.500 1.812 .375 3-53-2381
May use boot 212094X, order separate
3.500 .065 7.492 8.240 2 3.500 1.690 .500 3-53-02410
May use boot 212094X, order separate
3.500 .065 7.492 8.240 2 3.500 1.690 .500 5002410•
5002410 was replaced by 3-53-02410; May use boot 212094X, order separate
3.500 .083 7.715 8.080 2 3.500 1.800 .375 3-53-2441
May use boot 212094X, order separate
3.500 .083 8.838 9.618 2 3.500 1.809 .540 3-53-08002
3.500 .083 8.838 9.618 2 3.500 1.809 .540 5008002•
5008002 was replaced by 3-53-08002
3.500 .083 9.510 10.630 2 3.500 1.810 .880 3-53-2591
May use boot 212094X or 211010X, order separate
1.5000-15 Based On 16 Spline
1.575 Bearing Diameter (C)
3.000 .083 8.240 9.375 2 3.000 1.812 .812 3-53-1551
May use 211158X dust cap (or) 211600X or 212010X boot kit,
3.000 .083 9.500 10.625 2 3.000 1.810 .875 3-53-1951
May use boot 211503X, order separate
3.000 .095 8.234 9.350 2 3.000 1.812 .875 3-53-2291
May use boot 212010X, order separate
3.500 .065 8.230 9.350 2 3.000 1.810 .875 3-53-2011
3.500 .083 9.625 10.719 2 3.000 1.810 .875 3-53-2281
May use boot 211916X or dust cap 211158X, order separate
4.000 .083 9.500 10.625 2 3.000 1.810 .875 3-53-2181•
May use boot 211503X, order separate
4.095 .180 9.500 10.625 2 3.000 1.810 .875 3-53-1981•
1.5000-16 Spline
1.575 Bearing Diameter (C)
3.000 .083 5.940 7.062 1 4.438 1.810 .875 3-53-1031
3.000 .083 7.188 8.312 1 5.688 1.810 .875 3-53-1041•
3.000 .083 8.080 9.200 1 6.580 1.810 .875 3-53-1531
3.000 .083 9.040 10.160 1 7.540 1.810 .875 3-53-1481•
3.500 .083 5.940 7.062 1 4.440 1.810 .875 3-53-1121
4.000 .083 5.940 7.062 1 4.438 1.810 .875 3-53-1131
